8.4.4

Trusted Computing Submenu

Feature
Security Device Support
User Confirmation
TPM State
Pending operation
8.4.5

RTC Wake Submenu

Feature
Wake System At Fixed Time
Wake up hour
Wake up minute
Wake up second
8.4.6

Reserve Legacy Interrupt Submenu

Feature
Reserve Legacy Interrupt 1
Reserve Legacy Interrupt 2
Reserve Legacy Interrupt 3
Copyright © 2015 congatec AG
Options Description
Disabled
Enable or disable TPM support. System reset is required after change.
Enabled
Disabled Enable or disable user confirmation requests for certain transactions.
Enabled
Disabled Enable or disable TPM chip.
Enabled Note: System might restart several times during POST to acquire target state.
None, Perform selected TPM chip operation.
Enable Take Ownership, Note: System might restart several times during POST to perform selected operation.
Disable Take Ownership,
TPM Clear
Options Description
Disabled Enable system to wake from S5 using RTC alarm.
Enabled
Specify wake up hour. For example, enter "3" for 3am and "15" for 3pm.
Specify wake up minute.
Specify wake up second.
Options Description
None, IRQ3, IRQ4, IRQ5, The interrupt reserved here will not be assigned to any PCI or PCI Express device and thus maybe available for
IRQ6, IRQ10, IRQ11, IRQ14, some legacy bus device.
IRQ15
Same as Reserve Legacy Same as Reserve Legacy Interrupt 1
Interrupt 1
Same as Reserve Legacy Same as Reserve Legacy Interrupt 1
Interrupt 1
IA30m10 59/82
