Specification

2.1

Feature List

Table 1 Feature Summary
Form Factor
Processor
Memory
cBC
Chipset
Audio
Ethernet
Graphics
Graphic Interfaces
Back Panel I/O
Connectors
Onboard I/O
Connectors
Other Features
Copyright © 2015 congatec AG
Based on Thin Mini-ITX form factor (170 x 170 mm).
Intel 3 Generation Atom/Celeron SoC
® rd
2x SO-DIMM dual channel non-ECC DDR3L memory, up to 1333 MT/s with 16GB maximum capacity. Sockets located top side of module.
Multi-stage watchdog, non-volatile user data storage, manufacturing and board information, board statistics, I2C bus, Power loss control.
Integrated in the SoC
Realthek ALC888s 7.1 channel High Definition Audio codec
2x Gigabit Ethernet support via the onboard Intel
Intel HD Graphics with support for DirectX11, OpenGL 3.0, OpenCL 1.2, OpenGLES 2.0, full HW acceleration for decode/encode of MPEG2, H.264,
®
MVC and dual simultaneous display support and support for dual simultaneous displays.
1x DD1 (DP, HDMI/DVI) and 1x eDP/LVDS
1x DisplayPort ++ (DP++). Supports DP/DVI/HDMI
1x HDMI 1.4: Multiplexed with DisplayPort (DP)/DVI. Hot-plug
-
detect support.
1x DVI: Multiplexed with HDMI/DP ports. Hot-Plug detect
-
support.
1x VGA
1x LVDS (top side)
1x eDP interface (bottom side)
1x Backlight
1x Monitor OFF
SATA Interfaces
2x Standard SATA II (3.0 Gb/s).
-
1x mini SATA II (shared with mini PCIe Slot )
-
1x SATA power header connector (3.3V, 5V or 12V)
-
PCI Express Interfaces
1x PCI Express Slot (x1 Gen 2 link).
®
-
1x Hall size mini PCIe Slot
-
1x Full size mini PCIe Slot (shared with mSATA)
-
optional SIM card slot via connector X6 (Full size mPCIe/mSATA)
-
2x USB 2.0
2x USB 3.0
Thermal and voltage monitoring
CMOS Battery
Beeper
congatec Standard BIOS (also possible to boot from an external BIOS by triggering the BIOS_DISABLE# signal on the feature connector)
I210/I211 Phy.
®
1x Audio OUT/MIC
2x Gigabit Ethernet (without AMT)
2x USB 2.0
2x USB 3.0
1x DC-IN
1x MicroSD slot (located at the bottom side)
1x Front panel HD audio
1x SPDIF/Digital microphone
1x Stereo speaker
Connectors supported via Super IO
2x COM ports (COM 1 can be used optionally as ccTALK)
-
1x CPU fan with selectable voltage
-
1x System fan with selectable voltage
-
1x Case Open Intrusion Detection header
-
GPOs on feature connector
-
Feature connector (GPIOs, SPI, SMB, LPC, LID/SLEEP etc)
1x Front panel header (Power button, reset, LEDs etc)
1x optional SBM
1x Internal power header (12-24V)
1x optional SBM
IA30m10
3 support header
3 power
12/82
