8

BIOS Setup Description

The following section describes the BIOS setup program. The BIOS setup program can be used to view and change the BIOS settings for the
module. Only experienced users should change the default BIOS settings.
8.1

Entering the BIOS Setup Program.

The BIOS setup program can be accessed by pressing the <DEL> or <F2> key during POST.
8.1.1

Boot Selection Popup

Press the <F11> key during POST to access the Boot Selection Popup menu. A selection menu displays immediately after POST, allowing the
operator to select either the boot device that should be used or an option to enter the BIOS setup program.
8.2

Setup Menu and Navigation

The congatec BIOS setup screen is composed of the menu bar, left frame and right frame. The menu bar is shown below:
Main Advanced
The left frame displays all the options that can be configured in the selected menu. Grayed-out options cannot be configured. Only the blue
options can be configured. When an option is selected, it is highlighted in white.
The right frame displays the key legend. Above the key legend is an area reserved for text messages. These text messages explain the options
and the possible impacts when changing the selected option in the left frame.
Note
Entries in the option column that are displayed in bold indicate BIOS default values.
Copyright © 2015 congatec AG
Chipset Boot Security Save & Exit
IA30m10 52/82
