8.4.16

SCC Configuration Submenu

Feature
SCC Device Mode
SCC eMMC Support
SCC 4.5 DDR50 eMMC Support
SCC 4.5 HS200 eMMC Support
eMMC Secure Erase
SCC SD Card Support
SDR25 Support for SD Card
DDR50 Support for SD Card
8.4.17

PCI Subsystem Setting Submenu

Feature
PCI Bus Driver Version
PCI Latency Timer
PCI-X Latency Timer
VGA Palette Snoop
PERR# Generation
SERR# Generation
Above 4G Decoding
SR-IOV Support
Copyright © 2015 congatec AG
Options Description
ACPI Mode Configure the storage control cluster working mode.
PCI Mode
Enable eMMC 4.5 Support Enable SCC eMMC support and configure eMMC mode.
Enable eMMC 4.41 Support
eMMC AUTO MODE
Disable
Enabled Enable DDR50 eMMC support.
Disabled
Enabled Enable DDR50 eMMC support.
Disabled
Enabled Enable eMMC secure erase support.
Disabled
Enabled Enable storage control cluster SD Card support
Disabled
Enabled Enable SDR25 Support for SD Card
Disabled
Enabled Enable DDR50 Support for SD Card
Disabled
Options Description
32, 64, 96, 128, Select value to be programmed into PCI latency timer register.
160, 192, 224, 248
PCI Bus Clocks
32, 64, 96, 128, Select value to be programmed into PCI-X latency timer register.
160, 192, 224, 248
PCI Bus Clocks
Disabled Enable or disable VGA palette registers snooping.
Enabled
Disabled Enable or disable PCI device to generate PERR#.
Enabled
Disabled Enable or disable PCI device to generate SERR#.
Enabled
Disabled Enable or Disable 64bits capable Devices to be Decoded in Above 4G Address Space (Only if system supports 64 bits
Enabled PCI Decoding)
Disabled If system has SR-IOV capable PCIe Devices, this option enables or disables Single Root IO Virtualization support
Enabled
IA30m10 67/82
