  • Page 1 Manual congatec conga-PA5 The information contained in this document has been carefully researched and is, to the best of our knowledge, accurate. However, we assume no liability for any product failures or damages, immediate or consequential, resulting from the use of the information provided herein. Our products are not intended for use in systems in which failures of product could result in personal injury.
  • Page 2 Pico-ITX SBC Detailed Description Of The congatec Pico-ITX Based On 5 Generation Intel® Atom™, Celeron® and Pentium® User's Guide Revision 0.1 (Preliminary)
  • Page 3 Revision History Revision Date (yyyy.mm.dd) Author Changes 2017.03.17 Preliminary release • Copyright © 2017 congatec AG PA50m01 2/46...
  • Page 4 In no event shall congatec AG be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in connection with this user’s guide or any other information...
  • Page 5 Copyright © 2017, congatec AG. All rights reserved. All text, pictures and graphics are protected by copyrights. No copying is permitted without written permission from congatec AG. congatec AG has made every attempt to ensure that the information in this document is accurate yet the information contained within is supplied “as-is”.
  • Page 6 fitness for a particular purpose, or (c) arising from course of performance, course of dealing, or usage of trade. congatec AG shall in no event be liable to the end user for collateral or consequential damages of any kind. congatec shall not otherwise be liable for loss, damage or expense directly or indirectly arising from the use of the product or from any other cause.
  • Page 7 Technical Support congatec AG technicians and engineers are committed to providing the best possible technical support for our customers so that our products can be easily used and implemented. We request that you first visit our website at www.congatec.com for the latest documentation, utilities and drivers, which have been made available to assist you.

  • Page 8: Table Of Contents

    Environmental Specifications ........... 16 6.1.3 GPIOs ..................37 Block Diagram ................17 6.1.4 Micro-SD Card ................. 38 congatec Board Controller (cBC) ..........38 Cooling Solution ..............18 6.2.1 Fan Control ................38 6.2.2 Power Loss Control ..............38 CSP Dimensions for Industrial Module Variants ....... 19 6.2.3...
  • Page 9 BIOS Setup Description ............44 Additional BIOS Features ............45 Industry Specifications ............. 46 Copyright © 2017 congatec AG PA50m01 8/46...
  • Page 10 List of Tables Table 1 conga-PA5 Commercial Variants ..........11 Table 2 conga-PA5 Industrial Variants ..........11 Table 3 Accessories ................12 Table 4 Cables ..................12 Table 5 Cable Kit .................. 12 Table 6 Feature Summary ..............13 Table 7 Measurement Description ............

  • Page 11: Introduction

    PCI Express, SATA, USB 2.0/3.0, Ethernet, Displays and Audio. conga-PA5 The conga-PA5 is a Single Board Computer design based on the Pico-ITX specification. The conga-PA5 SBC features the Intel 5 generation Atom, Celeron and Pentium processors. With maximum 12 W TDP processors, the SBC offers Ultra Low Power boards with high computing performance and outstanding graphics.

  • Page 12: Options Information

    1.2.1 Options Information The conga-PA5 is currently available in 9 variants. This user’s guide describes all of these variants. The tables below show the different configurations available. Check for the Part No. that applies to your product. This will tell you what options described in this user’s guide are available on your particular module.

  • Page 13: Optional Accessories

    048152 Passive Cooling for Pico ITX board conga-PA5 (for boards with standard (non lidded) CPUs) conga-PA5/i-CSP-T 048153 Passive Cooling for Pico ITX board conga-PA5 (for boards with lidded CPUs -with integrated heat spreader) 1.2.3 Optional Cables Table 4 Cables Article Part No.

  • Page 14: Specification

    Thermal and voltage monitoring, RTC Battery, congatec standard BIOS BIOS AMI Aptio ® UEFI 5.x firmware, 16 MB SPI flash with congatec embedded BIOS features. Power ACPI 4.0 compliant with battery support. Also supports Suspend to RAM (S3). Ultra low standby power consumption.

  • Page 15: Supported Operating Systems

    Supported Operating Systems The conga-PA5 supports the following operating systems. • Calypso Island • Microsoft ® Windows ® • Microsoft ® Windows ® 10 IoT ® ® • Microsoft Windows Embedded Standard 7, 8 • Linux (Wind River, Yocto) • Android •...

  • Page 16: Table 7 Measurement Description

    2. All other peripherals except the LCD monitor were disconnected before measurement. Table 8 Power Consumption Values The tables below provide additional information about the power consumption data for each of the conga-PA5 variants offered. The values are recorded at various operating mode. Part...

  • Page 17: Supply Voltage Battery Power

    3. Consider also the self-discharge of the battery when calculating the lifetime of the CMOS battery. For more information, refer to application note AN9_RTC_Battery_Lifetime.pdf on congatec AG website at www.congatec.com/support/application-notes. 4. We recommend to always have a CMOS battery present when operating the conga-PA5. Environmental Specifications...

  • Page 18: Block Diagram

    PCIe SD Card PCIe Intel I211* I²C Ethernet SATA USB 2.0 USB 3.0 eMMC GPIO *I210IT for industrial temperature DP++ Watchdog DP++ Buttons SATA Power +12V +12V +3V Battery External I/O Internal I/O Copyright © 2017 congatec AG PA50m01 17/46...

  • Page 19: Cooling Solution

    The gap pad material used on all heatspreaders contains silicon oil that can seep out over time depending on the environmental conditions it is subjected to. For more information about this subject, contact your local congatec sales representative and request the gap pad material manufacturer’s specification.

  • Page 20: Csp Dimensions For Industrial Module Variants

    CSP Dimensions for Industrial Module Variants Copyright © 2017 congatec AG PA50m01 19/46...

  • Page 21: Csp Dimensions For Commercial Module Variants

    CSP Dimensions for Commercial Module Variants Copyright © 2017 congatec AG PA50m01 20/46...

  • Page 22: Hsp Dimensions For Industrial Module Variants

    HSP Dimensions for Industrial Module Variants Copyright © 2017 congatec AG PA50m01 21/46...

  • Page 23: Hsp Dimensions For Commercial Module Variants

    HSP Dimensions for Commercial Module Variants Copyright © 2017 congatec AG PA50m01 22/46...

  • Page 24: Connector Description

    Connector Description Power Supply You can power the conga-PA5 SBC with a 12V, 5.5x2.5mm laptop type DC power supply (on connector X21) or with a 2 pin power supply (on connector X22). Note The supplied voltages must be within a tolerance of ± 10%. The conga-PA5 may not function if you exceed this tolerance limit.

  • Page 25: Power Supply (Internal Connector)

    Possible Mating Connector: Molex 43645-0200 Note For conga-PA5 commercial variants, you can use connector X22 as a +12V power output if the system is powered via the DC jack. The industrial variants have only connector X22 for power input. Caution The absolute maximum rating of the input voltage is 13.2 volts.

  • Page 26: Rtc Battery

    For the feature connector pinout description, see section 6.1 “Feature Connectors”. RTC Battery The conga-PA5 provides an RTC battery on connector X23. The battery monitors and maintains the system clock. The conga-PA5 package contains wired +3V lithium battery (CR2032 for commercial variants; BR2330A for industrial variants).

  • Page 27: Audio Interface

    Universal Serial Bus (USB) The conga-PA5 provides 6 USB ports both on the rear side and internally. The rear side has two USB 3.0 ports on connector X7 and one USB 3.0 port on USB type C (X9). Internally, the conga-PA5 provides two USB 2.0 ports on connector X8 and one USB 2.0 port is connected to the miniPCIe slot.

  • Page 28: Rear Usb Connectors

    Rear USB Connectors The conga-PA5 offers three USB ports on the rear side by default - two USB 3.0 ports (X7) and one USB Type-C (X9). USB Type-C supports Alternate mode (DisplayPort and USB 3.0) and it can provide +5V / 3A power.

  • Page 29: Ethernet 10/100/1000

    Standard SATA Port The conga-PA5 provides one standard SATA port on connector CN1. This interface is routed directly from the SoC and supports data rates up to 6GB/s. The SATA LED signal on the feature connector X18 indicates activity on the SATA interface.

  • Page 30: Mini Sata (Shared With Mini Pcie)

    Mini SATA (shared with mini PCIe) The mini SATA connector X10 on the conga-PA5 is used to connect mSATA devices. This connector also supports mini PCIe devices. When an mSATA or mPCIe device is connected to X10, the conga-PA5 automatically detects the type of device that is attached.

  • Page 31: Display Port Interface Dp

    5.7.1 Display Port Interface DP++ The conga-PA5 SBC has one DP++ connector (X5) located at the rear I/O panel. The display port supports DP displays and HDMI / DVI adapters. DP++ - Connector X5 Connector Type X5: 20 pin DisplayPort connector 5.7.2...

  • Page 32: Backlight Power Connector

    5.7.2.1 Backlight Power Connector The conga-PA5 provides backlight power on connector X4. The connector supports 5V or 12V backlight power. The backlight fuse limits the power budget of pins 1 and 5 by 1.5A hold current. Table 17...

  • Page 33: Panel Power Selection

    Serial Ports (COM) The conga-PA5 provides two UART interfaces - connector X15 & X16. The COM ports are located at the bottom side of the SBC and can drive up to 250 kbit/s each and support multi-protocol serial ports (RS232 / RS422 / RS485). The serial ports are configurable in BIOS menu.

  • Page 34: Mini Pcie (Shared With Mini Sata)

    Mini PCIe (shared with mini SATA) The conga-PA5 offers a mini PCIe slot on connector X10. This connector supports both mPCIe and mSATA devices. The PCIe and SATA signals are routed from the SoC to connector X10 (mPCIe/mSATA slot) via a multiplexer. The multiplexer switches the incoming signals based on the type of card inserted.
  • Page 35 Note For the conga-PA5 to detect the type of card inserted as described in the mPCIe/mSATA specification, pin 43 of the mPCIe card must be connected to ground. On mSATA card, this pin must not be connected. The miniPCIe extender can be used for miniPCIe half size cards.

  • Page 36: Additional Features

    LEDs, I2C, watchdog, GPIOs via these connectors. 6.1.1 Buttons & LEDs The conga-PA5 offers Lid, sleep, reset, power buttons as well as LED signals via the feature connector X18. The pinout is described below: Table 21 Feature Connector X18 Pinout Description...

  • Page 37: I2C And Watchdog

    6.1.2 I2C and Watchdog The conga-PA5 offers I2C and watchdog signals via the feature connector X19. The pinout is described below: Table 22 Feature Connector X19 Pinout Description Signal Name Feature Connector X19 BATLOW# +3.3V LED_WLAN# (mPCIe) I2C_CLK I2C_DAT GN D...

  • Page 38: Gpios

    6.1.3 GPIOs The conga-PA5 offers GPIOs via the feature connector X20. It offers an optional connection to the integrated sensor hub (ISH), which is a feature of Intel ® processor. A sensors can be connected via I2C and GPIO (voltage level is 1.8V for ISH). The pinout is described below:...

  • Page 39: Micro-Sd Card

    6.1.4 Micro-SD Card The conga-PA5 offers a micro-SD slot on connector X14. The SD card slot complies with SDXC card specification 3.0 with support for up to 104 MBps data rate. Micro-SD Slot (Connector X14) Connector Type X14: Micro-SD card socket congatec Board Controller (cBC) The conga-PA5 is equipped with a Texas Instruments Tiva™...

  • Page 40: Cpu Fan Connector

    6.2.4 CPU Fan Connector The conga-PA5 supports 12V cooling fans. The signals of the CPU fan are routed to connector X17. The pinout is described below: Table 24 CPU Fan Connector (X17) Pinout Description CPU Fan Signal (X17) +12VDC FAN_TACHOIN Connector Type X17: 2.54mm, 3 pin fan connector...

  • Page 41: Oem Boot Logo

    OEM POST Logo This feature allows system designers to replace the congatec POST logo displayed in the upper left corner of the screen during BIOS POST with their own BIOS POST logo. Use the congatec system utility CGUTIL 1.5.4 or later to replace/add the OEM POST logo.

  • Page 42: Api Support (Cgos)

    The architecture of the CGOS API driver provides the ability to write application software that runs unmodified on all congatec CPU modules. All the hardware related code is contained within the congatec embedded BIOS on the module. See section 1.1 of the CGOS API software developers guide, which is available on the congatec website.

  • Page 43: Security Features

    Security Features The conga-PA5 can be equipped optionally with a “Trusted Platform Module“ (TPM 1.2/2.0). This TPM 1.2/2.0 includes coprocessors to calculate efficient hash and RSA algorithms with key lengths up to 2.048 bits as well as a real random number generator. Security sensitive applications like gaming and e-commerce will benefit also with improved authentication, integrity and confidence levels.

  • Page 44: Mechanical Drawing

    Mechanical Drawing 30.6 30.6 Copyright © 2017 congatec AG PA50m01 43/46...
  • Page 45 BIOS Setup Description Copyright © 2017 congatec AG PA50m01 44/46...
  • Page 46 Additional BIOS Features Copyright © 2017 congatec AG PA50m01 45/46...
  • Page 47 Industry Specifications The list below provides links to industry specifications that apply to congatec AG products. Specification Link Low Pin Count Interface Specification, Revision 1.0 (LPC) http://developer.intel.com/design/chipsets/industry/lpc.htm Universal Serial Bus (USB) Specification, Revision 2.0 http://www.usb.org/home Serial ATA Specification, Revision 3.0 http://www.serialata.org...
