B7 GND
B8 +3.3V
B9 N.C.
B10 +3.3V Aux
B11 WAKE#
Key
B12 N.C.
B13 GND
B14 PCIE_TX0+
B15 PCIE_TX0-
B16 GND
B17 PRSNT2#
B18 GND
Connector Type
X9: PCIe x1 Connector
Note
The PCIe x1 slot on connector X9 will not function if you insert a mini PCIe card into the mPCIe slot (connector X6). To use the PCIe x1 slot,
do not insert any device into the mPCIe slot.
5.9.2

Mini PCIe (Half Size)

The conga-IA3 is equipped with a PCI Express Mini Card socket. PCI Express Mini Card is a unique small size form factor optimized for mobile
computing platforms equipped with communication applications. The small footprint connector can be implemented on SBCs, providing the
ability to insert different removable PCI Express Mini Cards. Using this approach gives the flexibility to mount an upgradable, standardized PCI
Express Mini Card device to the SBC without additional expenditure of a redesign. The table below lists the default pinout of the PCI Express
Mini Card.
mPCIe (Connector X10) Pinout Description
Pin Signal
1 WAKE#
3 N.C.
Copyright © 2015 congatec AG
A7 N.C.
A8 N.C.
A9 +3.3V
A10 +3.3V
A11 PCIE_RST#
A12 GND
A13 PCIE_CLK+
A14 PCIE_CLK-
A15 GND
A16 PCIE_RX0+
A17 PCIE_RX0-
A18 GND
Pin Signal
2 +3.3Vaux
4 GND
