8.4.14

IDE Configuration Submenu

Feature
Serial-ATA (SATA)
SATA Test Mode
SATA Speed Support
SATA ODD Port
SATA Mode
Serial-ATA Port 0
SATA Port 0 Hot Plug
Serial-ATA Port 1
SATA Port 1 Hot Plug
SATA Port 0 Information
SATA Port 1 Information
8.4.15

Miscellaneous Configuration Submenu

Feature
High Precision Timer
Boot Timer with HPET Timer
PCI Express Dynamic Clock
Gating
Copyright © 2015 congatec AG
Options Description
Enabled
Enable or disable the onboard SATA controller.
Disabled
Enabled Should be set to Disabled.
Disabled
Test Mode is used just for verification measurements.
Gen1 Indicates the maximum speed the SATA controller can support.
Gen2
Port 0 ODD Configure which SATA Port is ODD.
Port 1 ODD
No ODD
IDE Mode Configure SATA Port Mode
AHCI Mode
Enabled Enable or disable the SATA Port 0.
Disabled
Disabled Select hot plug support for SATA Port 0.
Enabled Not possible in Native IDE mode.
Enabled
Enable or disable the SATA Port 1.
Disabled
Disabled Select hot plug support for SATA Port 1.
Enabled Not possible in Native IDE mode.
No Option Displays Information of device detected on SATA Port 0.
No Option Displays Information of device detected on SATA Port 1.
Options Description
Enabled Enable or disable the high precision event timer.
Disabled
Enabled Allow boot timer calculation with the high precision event timer.
Disabled
Enabled Enable dynamic clock gating.
Disabled
IA30m10 66/82
