8.4.10

Serial Port Console Redirection Submenu

Feature
COM0
Console Redirection
►Console Redirection Settings submenu
Serial Port for Out-of-Band
Management / EMS
Console Redirection
►Console Redirection Settings Submenu
8.4.10.1

Console Redirection Settings COM0 Submenu

Feature
Terminal Type
Baudrate
Data Bits
Parity
Stop Bits
Flow Control
VT-UTF8 Combo Key Support
Recorder Mode
Resolution 100x31
Legacy OS Redirection
Resolution
Copyright © 2015 congatec AG
Options
Description
Disabled
Enable or disable serial port 0 console redirection.
Enabled
Opens console redirection configuration sub menu.
Disabled
Enable or disable Serial Port for Out-of-Band Management / Windows Emergency Management Services.
Enabled
Opens console redirection configuration sub menu.
Options
Description
VT100
Select terminal type.
VT100+
VT-UTF8
ANSI
9600, 19200, 38400, 57600,
Select baud rate.
115200
7,
Set number of data bits.
8
None
Select parity.
Even
Odd
Mark
Space
1
Set number of stop bits.
2
None
Select flow control.
Hardware RTS/CTS
Disabled
Enable VT-UTF8 combination key support for ANSI/VT100 terminals
Enabled
Disabled
With recorder mode enabled, only text output will be sent over the terminal. This is helpful to capture and
Enabled
record terminal data.
Disabled
Enable or disable extended terminal resolution.
Enabled
80x24
Number of rows and columns supported for legacy OS redirection.
80x25
IA30m10
62/82
