Miscellaneous Brake Information
• The caliper from either Lincoln will bolt on to the Mustang spindle although the piston is 73mm in
diameter, so it would not be well suited for the recommended brake setups above. If this caliper is
used, a 1" master cylinder from a '93 Mustang Cobra, 84-86 Mustang SVO or Bendix # 12669,
although this is not an ideal setup.
• Thunderbird Super Coupe 5-lug rear brakes have a 4.25" bolt circle where as the Mustang 5-lug
bolt pattern uses a 4.5" bolt circle. The IRS hubs need to be drilled to the Mustang pattern. FFR
supplies new studs with the IRS kit.
• If you desire a dual master cylinder set up (having individual master cylinders for the front and
rear), the following information will help with those installations:
There are several different versions on the market. Dual master cylinder units usually use a
balance bar to proportion the amount of line pressures from the front to rear, so no
proportioning valve is necessary. We have used a unit from CNC brakes (part # 241). This
unit uses the Mustang bolt pattern, so it will simply bolt to the FFR foot box. Use the
following table to determine each master cylinder required.
Baer Brakes
Stainless Steel Brakes Corporation
Disc Brakes R' Us
Forte's Parts Connection, Inc. (Ford Motorsport Dealer)
CNC, Inc.
AFCO Racing Products (supplier of CNC components)
Mustang Part's Specialties, Inc.
Porterfield Enterprises Ltd.
Carbotech Engineering
Hawk Brake, Inc.
• To calculate piston area, use the following equation: πr
• If using calipers with more than one piston, calculate the area for each piston, and then add the
areas together. If the caliper has pistons on both sides of the rotor, disregard one side.
Superchargers
Caliper
Master Cylinder
Piston Area
Bore Diameter
2
(in
)
(in)
Up to 3.6
3.6 to 4.2
4.2 to 4.5
4.5 to 4.7
4.7 to 5.5
5.5 to 5.9
5.9 to 6.3
6.3 to 7.6 max
195
www.factoryfive.com
508-291-3443
⅝
7
/
10
¾
13
/
16
⅞
15
/
16
1
1⅛
602-233-1411
www.baer.com
800-448-7722
www.ssbrakes.com
888-558-5757
www.discbrakesrus.com
781-647-1530
www.fortesparts.com
619-275-1663
812-897-0900
www.afcoracing.com
770-867-2644
www.stangparts.com
800-537-6842
954-493-9669
800-542-0972
www.hawkbrake.com
2
(3.14159 x radius squared.)
