Home > Wan > Compression - Comtech EF Data CDM-625A Installation And Operation Manual

CDM-625A Advanced Satellite Modem
Telnet Command Line Interface (CLI) Operation
9.3.5.2 Home > WAN > Compression
Open the Compression page from the WAN submenu. This page contains the following options:
Hot
Dialog Window
Key
A Header Comp RTP Refresh Rate
B
Header Comp UTD Refresh Rate
C
Header Comp Default Refresh Rate
D
Payload Comp Refresh Rate
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the WAN submenu.
Option Entry
Typical for each entry – Enter a value from 1 to 600
Enter a value from 1 to 255
9–60
Revision 0
MN-CDM625A
