Comtech EF Data CDM-625A Installation And Operation Manual page 306

CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Rx Clock RCK= 1 byte, value of
Source 0 thru 3
Rx Clock Invert RCI= 1 byte, value 0 or
1
Eb/No Alarm EBA= 4 bytes
Point
Rx Buffer Size RBS= 5 bytes
Rx Audio RVL= 4 bytes
Volume Control
Receive RTE= 1 byte, 0 or 1
Terrestrial
Alarm Enable
Insert Type ITY= 1 byte, value of
0 thru 3
Description of Arguments
Command or Query.
Rx Clock Source in the form x, where:
0=Rx Satellite
1=Tx-Terrestrial
2=Internal(SCT)
3=INSERT (command valid only when Rx framing is Insert or D&I++ and interface is G.703 or set for D&I loop)
Example: RCK=1 (selects Tx-Terrestrial)
Command or Query.
Invert Receive Clock, in the form x, where:
0=Normal
1=Inverted
Command or Query.
Eb/No alarm point in dB, with a range between 0.1 and 16 dB, in the form xx.x, where:
Resolution=0.1 dB
Example: EBA=12.3
Command or Query.
Rx Buffer Size, 16 to 32768 bytes, in 2-byte steps, unless other limitations apply.
(See Sect. 5.3.1.5.2)
Example: RBS=08192 (selects 8192 bytes)
Command or Query. (Audio/IDR parameters)
Rx Audio Volume control, in the form aabb, where:
aa=Rx 1 volume control in dB, valid values are -6, -4, -2, +0, +2, +4, +6, +8;
bb=Rx 2 volume control in dB, valid values are -6, -4, -2, +0, +2, +4, +6, +8.
Example: RVL= -2+4 (sets Rx 1 to -2 dB and Rx 2 to +4 dB)
Command or Query. (INSERT mode parameter)
Receive Terrestrial Alarm Enable conditions in the form x, where:
0=Disables the alarm
1=Enables the alarm.
Example: RTE=0 (disables the alarm).
Command or Query. (INSERT/D&I++/QDI parameter)
Insert Type, in the form x where:
0=T1–D4
1=T1–ESF
2=E1–CCS
3=E1–CAS
8–24
Revision 0
MN-CDM625A
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
RCK= RCK? RCK=x
RCK?
RCK* (see Description of
RCK# Arguments)
RCI= RCI? RCI=x
RCI?
RCI* (see Description of
RCI# Arguments)
EBA= EBA? EBA=xx.x
EBA?
EBA* (see Description of
EBA# Arguments)
RBS= RBS? RBS=xxxxx
RBS?
RBS* (see Description of
RBS# Arguments)
RVL= RVL? RVL=aabb
RVL?
RVL* (see Description of
RVL# Arguments)
RTE= RTE? RTE=x
RTE?
RTE* (see Description of
RTE# Arguments)
ITY= ITY? ITY=x
ITY?
ITY* (see Description of
ITY# Arguments)
