A.1 Overview
The EIA-530 standard pinout, provided on the CDM-625A, is becoming more popular in many applications. However, there are still many
occasions – especially for existing EIA-422/449 and V.35 users – when a conversion is required. For these situations:
•
Figure A-1 depicts the cable required for EIA-530 -to- EIA-422/449 DCE conversion.
•
Figure A-2 depicts the cable required for EIA-530 -to- V.35 DCE conversion.
•
Figure A-3 depicts a standard EIA-232 cable for connection between the CDM-625A Rear Panel Remote Control port and any
serial port on the user PC.
All dimensions, where specified in the illustrations featured in this appendix, are in inches.
Appendix A. CABLE DRAWINGS
A-1
