CDM-625A Advanced Satellite Modem
Telnet Command Line Interface (CLI) Operation
9.3.3.5 Home > Modem > Adaptive Coding and Modulation (ACM)
Appendix M. ADAPTIVE CODING
Open the ACM page from the Modem submenu. Use this page as a quick reference guide for the
Minimum and Maximum Tx ModCod settings. This submenu contains the following options:
Hot
Dialog Window
Key
A ACM Min Tx Mod Cod
B
ACM Max Tx Mod Cod
C
ACM Action on Remote Demod Unlock
D
ACM Target Eb No Margin
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Modem
submenu.
MODULATION (ACM) OPTION
AND
Option Entry
Enter a minimum value from 0 to 11
Enter a maximum value from 0 to 11
Use the ↑↓ arrow keys to select Go To Min Tx Modcod or
Maintain Tx Modcod
Enter a value from 0.0 to 4.5 dB
9–29
Revision 0
MN-CDM625A
