CDM-625A Advanced Satellite Modem
Appendix L
L.3.2.1 SNMP Interface
Sect. 7.3 SNMP Interface (Chapter 6. ETHERNET-BASED REMOTE PRODUCT
MANAGEMENT)
The Simple Network Management Protocol (SNMP) is an Internet-standard protocol for managing
devices on IP networks. An SNMP-managed network consists of three key components:
The managed device – This includes the CDM-625A Advanced Satellite Modem.
•
The SNMP Agent – The software that runs on the CDM-625A. The CDM-625A SNMP
•
Agent supports both SNMPv1 and SNMPv2c.
The user-supplied Network Management System (NMS) – The software that runs on
•
the manager.
L.3.2.2 Telnet Interface
•
Sect. 7.4 Telnet Interface (Chapter 7. ETHERNET-BASED REMOTE PRODUCT
MANAGEMENT)
•
Chapter 8. SERIAL-BASED REMOTE PRODUCT MANAGEMENT
• Chapter 9. TELNET COMMAND LINE INTERFACE (CLI) OPERATION
Comtech EF Data provides a Telnet interface for the purpose of equipment monitor and control
(M&C) using either the standard remote control protocol or, when the optional IP Packet
Processor is installed and enabled
Figure L-1. CDM-625A Telnet Interfaces Interfaces (Serial Remote / CLI)
L.3.2.3 Web Server (HTTP) Interface
Sect. 7.5 Web Server (HTTP) Interface (Chapter 6. ETHERNET-BASED REMOTE
PRODUCT MANAGEMENT)
The embedded Web Server (HTTP) application (
Figure L-2) provides an easy to use interface designed for optimal performance when using
Microsoft's Internet Explorer Version 9.0 or higher. The interface features enhanced
functionality when the CDM-625A is equipped with the IP Packet Processor.
, the Telnet Command Line Interface (CLI) (
L–6
Revision 0
MN-CDM625A
Figure L-1 ).
