Comtech EF Data CDM-625A Installation And Operation Manual page 343

CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Packet PPE= 1 byte, value
Processor Card 0 or 1
Enable
QoS Mode QOS= 2 bytes
Switch Ports SPC= 47 bytes
Configuration
Edit entry in SVE= 8 bytes
VLAN table
Command or Query.
Packet Processor Card Enable, in the form PPE=x, where:
0 = Packet Processor Card is Disabled
1 = Packet Processor Card is Enabled
Note: Change of this configuration results in modem auto-reboot only when IP Packet Processor option card is installed
and enabled. Otherwise, when the IP Packet Processor option card is not installed, this selection is stored but is otherwise
non-functional.
Command or Query.
Qo (Quality of Service) Mode, in the form QOS=ab where:
a = Layer 2 QoS;
0 = Off, Layer 2 QoS is disabled
1 = VLAN Priority only
2 = Port Priority only
3 = VLAN and Port Priority
b =Layer 3 QoS;
0 = Off, Layer 3 QoS is disabled
1 = Advanced QoS Max / Priority (requires Advanced QoS FAST Option)*
2 = Advanced QoS Min Max (requires Advanced QoS FAST Option)*
3 = Advanced QoS DiffServ (requires Advanced QoS FAST Option)*
*Note: Layer 3 QoS settings 1 through 3 apply to modem only with IP Packet Processor option card installed and enabled.
Command or Query.
Sets/Returns Ethernet switch ports' priority and PVID in the form 1abccccdxxx;2abccccdxxx;3abccccdxxx;4abccccdxxx,
where:
1, 2. 3. 4 = Port number.
a = Port priority;
Value is 1, 2, 3 or 4 (the higher the number, the higher the priority).
b = Port Native Mode;
0 = Native Mode Disabled, 1 = Native Mode Enabled.
cccc = Port VLAN ID in the range of 0000-4095;
Value 0000 is only valid when port Native Mode is disabled.
d = Pause flow control;
0 = Off, 1 = On
xxx = Eeserved.
Command only.
Edit VLAN table entry in the form aaaabcde, where:
aaaa = existing VLAN ID. Value range is 1-4095.
b = property of port 1;
0=Tagged, 1=Filtered, 2=Untagged
c = property of port 2;
0=Tagged, 1=Filtered, 2=Untagged
d = property of port 3;
0=Tagged, 1=Filtered, 2=Untagged
e = property of port 4;
0=Tagged, 1=Filtered, 2=Untagged
Description of Arguments
8–61
Revision 0
MN-CDM625A
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
PPE= PPE? PPE=x
PPE? (see Description of
PPE* Arguments)
PPE#
QOS= QOS? QOS=ab
QOS? (see Description of
QOS* Arguments)
QOS#
SPC= SPC? SPC=1abccccdxxx,2ab
SPC? ccccdxxx,3abccccdxxx,
SPC* 4abccccdxxx
SPC# (see Description of
Arguments)
SVE= N/A SVE=aaaabcde
SVE? (see Description of
SVE* Arguments)
SVE#
