Comtech EF Data CDM-625A Installation And Operation Manual page 321

CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Antenna AHD= 3 bytes
Handover
Differential
Path Delay
Time Protocol TPE= 1 byte
Enable
Primary TPS= 15 bytes
Ethernet Time
Server
Backup TPB= 15 bytes
Ethernet Time
Server
Description of Arguments
Command or Query.
Differential Path Delayin the form +xx (-13 to +13)
Example: AHD=+12 (Lead 12)
AHD=-03 (Lag 3)
Command or Query.
Used to disable or enable the Time Protocol, where:
0 = Time Protocol disabled
1 = Time Protocol enabled
Example: TPE=1 (Time protocol enabled)
Command or Query.
Used to set the Primary Ethernet Time Server IP address for the Unit. Tx Ethernet management port, in the format:
xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx is the Time server IP address
Example: TPS = 192.168.001.005
Command or Query.
Used to set the Backup Ethernet Time Server IP address for the Unit. Tx Ethernet management port, in the format:
xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx is the Time server IP address
Example: TPB = 192.168.001.005
8–39
Revision 0
MN-CDM625A
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
AHD= AHD? AHD=xx
(see Description of
Arguments)
TPE= TPE? TPE=x
TPE? (see Description of
Arguments)
TPS= TPS? TPS= xxx.xxx.xxx.xxx
TPS? (see Description of
Arguments)
TPB= TPB? TPB= xxx.xxx.xxx.xxx
TPB? (see Description of
Arguments)
