CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
...Equipment ID
(cont.)
Description of Arguments
4=up to 5 Mbps
5=up to 10 Mbps
6=up to 15 Mbps
7=up to 20 Mbps
8=up to 25 Mbps
P=VersaFEC CCM data rate option, where:
0=No VersaFEC CCM FAST installed
1=up to 1.1Mbps
2=up to 2.5Mbps
3=up to 5 Mbps
4=up to 16Mbps
Q=IP-ACM symbol rate option, where:
0=None
1=up to 300ksym/sec
2=up to 1200ksym/sec
3=up to 4100ksym/sec
R=Framing option, where:
0=Standard: (Unframed, EDMAC, EDMAC2)
1 = Option 0 plus Open Network (IBS with hi-rate ESC, IDR, Audio)
S=D&I option, where:
0=None
1=D&I,D&I++ for single port E1/T1
2=Option 1 plus Quad D&I (4 ports)
T= G.703 Clock Extension, where:
0=Not installed
1=installed on
U=Time based CnC option, where:
0=Not installed
1=Fractional CnC installed
2=Time Limited CnC installed
3=Option 1 and Option 2
V=Header Compression, where:
0=None
1=up to 5Mbps / 1200ksps (ACM)
2=up to 10Mbps / 4100ksps (ACM)
3=up to 15Mbps / 4100ksps (ACM)
4=up to 20Mbps / 4100ksps (ACM)
5=up to 25Mbps / 4100ksps (ACM)
W=Payload Compression, where:
0=None
1=up to 5Mbps / 1200ksps (ACM)
2=up to 10Mbps / 4100ksps (ACM)
3=up to 15Mbps / 4100ksps (ACM)
4=up to 20Mbps / 4100ksps (ACM)
5=up to 25Mbps / 4100ksps (ACM)
8–48
Revision 0
MN-CDM625A
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
