CDM-625A Advanced Satellite Modem
CDM-625A ODU (Transceiver, BUC, LNB) Operation
10.5.1.2.1.7 Home > Outdoor Unit (ODU) > CSAT-5060 > Redundancy
Open the Redundancy page from the nested CSAT-5060 submenu. Redundant ODU
configuration options are as follows:
Hot
Dialog Window
Key
A Unit Red Force Switch
B
Unit Redundancy Mode
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the nested CSAT-
5060 submenu.
10.5.1.2.1.8 Home > Outdoor Unit (ODU) > CSAT-5060 > Utilities
Open the Utilities page from the nested CSAT-5060 submenu. This page contains the following
options:
Hot
Dialog Window
Key
A
Device Time
B
Device Date
The page additionally provides the model number, software version, and unit serial number of
the recognized ODU.
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the nested CSAT-
5060 submenu.
Option Entry
Use the ↑↓ arrow keys to select No or Yes
Use the ↑↓ arrow keys to select Manual or Auto
Option Entry
Enter a time in the form HH:MM:SS
Enter a date in the form DD/MM/YY
10–64
Revision 0
MN-CDM625A
