Comtech EF Data CDM-625A Installation And Operation Manual page 371

CDM-625A Advanced Satellite Modem
Telnet Command Line Interface (CLI) Operation
Hot
Dialog Window
Key
F
Tx Frequency
G
Tx Spectrum Invert
H Tx Scrambler
I Tx Power Level
Tx Reed-Solomon
J
Encoding
K Tx Data Invert
L Tx Data Clock Invert
M Tx Ternary Code
N
Tx Carrier State
O POCO
P
Tx Submux
Q Tx Submux Ratio
R Tx Filter Rolloff Factor
Valid code rates depend on the selected FEC and Mod types – for example, you
cannot select "VersaFEC 16QAM 0.644" if your FEC is "TCM"
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Modem
submenu.
Option Entry
Enter a value as follows:
Range 1 – From 50.0000 to 180.0000 MHz
•
Range 2 – From 950.0000 to 2250.0000 MHz
•
Use the ↑↓ arrow keys to select Normal or Inverted
Use the ↑↓ arrow keys to select Off, Normal, or IESS315
Enter a value as follows:
Range 1 – From -99.9 to 99.9 dBm
•
Range 2 – From-40.00 to 0.0 dBm
•
Use the ↑↓ arrow keys to select Normal, IESS410, EF Data, or IBS
Typical for either entry – Use the ↑↓ arrow keys to select Normal or Inverted
Use the ↑↓ arrow keys to select AMI, B8zs, B6zs, or Hdb3
Use the ↑↓ arrow keys to select:
• Off • On
• Off External • Off BUC delay
• RTI, 2 s timeout • RTI, 4 s timeout
Use the ↑↓ arrow keys to select Disabled or Enabled
Use the ↑↓ arrow keys to select Off or On
Use the ↑↓ arrow keys to select an IP/Synchronous setting:
• 1/9 • 1/8 • 1/7
• 2/7 • 1/3 • 2/5
• 2/3 • 3/4 • 4/5
• 3/2 • 5/3 • 2/1
• 7/2 • 4/1 • 5/1
• 9/1 • 1/59 • 1/39
Use the ↑↓ arrow keys to select a Tx Rolloff Factor:
• 0.05 • 0.10
• 0.20 • 0.25
9–25
Revision 0
MN-CDM625A
• RTI, 10 s timeout
• RTI, 1 s timeout
• RTI, 7 s timeout
• 1/6 • 1/5 • 1/4
• 3/7 • 1/2 • 3/5
• 1/1 • 5/4 • 4/3
• 7/3 • 5/2 • 3/1
• 6/1 • 7/1 • 8/1
• 1/19
• 0.15
• 0.30
