Comtech EF Data CDM-625A Installation And Operation Manual page 535

CDM-625A Advanced Satellite Modem
Appendix B
1
1E-1
Uncoded
BPSK/QPSK
1E-2
1E-3
Rate
0.488
BPSK
1E-4
1E-5
1E-6
1E-7
1E-8
1E-9
1
BER
2 3 4
Typical performance shown -
guaranteed performance curve
is 0.3 dB to the right
2 3 4
Figure B-18. VersaFEC Codec Rate 0.488 BPSK
5 6 7
Comtech VersaFEC® Codec
Rate 0.488 BPSK
5 6 7
B–31
Revision 0
MN-CDM625A
Eb/No in dB
