Chapter 3 Operating the Autoloader
Viewing Status Information
Viewing Status Information
Viewing
SuperLoader 3
Autoloader Status
3
34
To identify a slot:
Each slot has an identification number that is exposed when the slots are
in the upper section of the magazine. With the magazine removed from
the autoloader, you can see the identification mark on the top side of the
magazine through one of two windows on the upper surface of the
magazine.
Each magazine has a unique identification number indicating whether it
is the right or left magazine. The left magazine will indicate the number 1
and the right magazine will indicate the number 9.
From the scrolling menu on the LCD, you can view the autoloader status,
firmware version, element status, tape drive status, tape drive version,
and Ethernet information.
The autoloader status provides information about: whether a magazine is
installed or not, SCSI connection status, Ethernet connection status, and
whether a bar code reader is installed or not.
To view the autoloader status:
1 From the main menu, scroll to
2 From the
submenu, scroll to
Status
3 From the
Autoloader
A list of messages similar to the following appears:
SuperLoader 3 Autoloader User's Guide
, and then press
Status
Autoloader
submenu, scroll to
Status
.
Enter
, and then press
Enter
, and then press
Enter
3
3
.
.
