Chapter 7 Customer Replaceable Units (CRUs)

Replacing a Magazine or Magazine Blank

Replacing a Magazine or Magazine Blank
Removing a
Magazine 7
82
To replace a cartridge magazine or magazine blank, you need to remove
the current magazine or blank, and then install the new magazine or
blank. If you currently have a magazine blank and wish to change it to a
cartridge magazine, you must remove the blank first, and then insert a
cartridge magazine. This allows for up a maximum of 16 cartridges in the
autoloader, plus one cartridge in the drive.
Note: Handles are either right or left. They are not interchangeable
between the left and right sides of the autoloader.
In most cases, you will remove a magazine by using the
on the front panel menu. If you need to remove the magazine when the
autoloader is powered off, you must remove it manually. Please contact
Customer Support for more information.
Removing a magazine using the front panel
1 On the menu, scroll to
2 Press .
Enter
3 On the Commands submenu, scroll to
4 On the Eject submenu, scroll to
depending on which magazine you want to eject, and then press
.
Enter
The magazine pops forward so that the front of the magazine is no
longer flush with the front panel.
5 With one hand, grasp the magazine by the handle and slide it
forward to remove. Place your other hand under the magazine to
support it and prevent it from falling.
SuperLoader 3 Autoloader User's Guide
.
Commands
, and then press
Eject
Right Magazine
7
command
Eject
7
.
Enter
or ,
Left Magazine
