Figure 11 Required Parts For Installation - Freecom SUPERLOADER3 LTO2-HH Manual

Figure 11 Required
Parts for Installation
• The following parts shipped with the rack:
• Eight clip nuts
• Eight screws
Short autoloader
brackets (74-60604-03)
2 Install two clip nuts, 1.75 in. (44.45 mm) apart, onto each of the four
rails of the rack, making sure that you install each pair of clip nuts at
exactly the same level (see
SuperLoader 3 Autoloader User's Guide
Chapter 7 Customer Replaceable Units (CRUs)
Long autoloader
brackets (74-60604-01)
figure 12).
Rack Mounting the Autoloader
Support brackets
(74-60605-01)
Support bracket screws
89
