SNM-1001L Satellite Modem
Front Panel Operation
FUNCTION SELECT: CONFIGURATION: DEMODULATOR:
REACQUISITION
Programs the sweep reacquisition mode time duration. This is the time that the modem will
remain in a narrow sweep after loss of acquisition. After this timer runs out, the modem will
return to the normal acquisition sweep. The reacquisition time is 0 to 999 seconds.
Upon entry, the current programmed setting is displayed with a flashing cursor on the first
character. Press [←] or [→] to move the flashing cursor. Press [↑] or [↓] to increment or
decrement the digit at the flashing cursor. Select the number of seconds desired for the
reacquisition mode. Press <ENTER> to execute the change.
FUNCTION SELECT: CONFIGURATION: DEMODULATOR:

LNB POWER

Programs the LNB Power On or Off. The LNB voltage is transmitted up the center conductor of
the RF-IF connector.
Upon entry, the current status of the descrambler is displayed. Press [↑] or [↓] to make the
selection. Press <ENTER> to execute the change.
FUNCTION SELECT: CONFIGURATION: DEMODULATOR:

LNB VOLTAGE

Programs the LNB Power at 13, 18, or 24 VDC.
Upon entry, the current status of the descrambler is displayed. Press [↑] or [↓] to make the
selection. Press <ENTER> to execute the change.
REACQUISITION
0 SECONDS
LNB POWER
OFF
LNB VOLTAGE
13 VDC
4–24
Revision 1
MN/SNM1001L.IOM
