Bit Error Rate Performance

A.8.1

Performance With Noise, Viterbi Decoder, and Closed Network

A.8.2 Performance with Noise, Viterbi Decoder, and Reed-Solomon
A.8.3

Performance With BPSK and {O}QPSK BER Performance

BPSK and {O}QPSK
BER 1/2 Rate
10 -3 3.8
10 -4 4.6
10 -5 5.3
10 -6 6.0
10 -7 6.6
10 -8 7.2
(Optional)
Required Eb/No
BPSK and {O}QPSK
BER 1/2 Rate
10 -6 4.1
10 -7 4.2
10 -8 4.4
10 -10 5.0
Eb/No (db) Specification
BER
10 -3
10 -4
10 -5
10 -6
10- 7
Required Eb/No
3/4 Rate 7/8 Rate
4.9 6.1
5.7 6.9
6.4 7.6
7.2 8.3
7.9 8.9
8.5 9.6
3/4 Rate 7/8 Rate
5.6 6.7
5.8 6.9
6.0 7.1
6.3 7.5
Required Eb/No
1/1
8.0
9.6
10.8
11.6
12.4
A–19
MN/SNM1001L.IOM
2/3 8PSK
-
-
-
8.7
9.5
10.2
2/3 8PSK
6.1
6.4
6.6
7.2
Revision 1
