FUNCTION SELECT: UTILITY: INTERFACE: BUFFER PROGRAM

Allows selection of either Bits or Milliseconds for the receive buffer.
•
•
IMPORTANT
FUNCTION SELECT:UTILITY: INTERFACE: RTS TX-IF CNTRL
Programs the modem to allow a Request To Send (RTS) signal to enable or disable the output carrier
when data is ready for transmission.

FUNCTION SELECT: UTILITY: INTERFACE: TX DATA PHASE

TX data phase relationship. Use this option to select Normal or Invert for the TX data relationship to
the selected TX clock.
BUFFER PROGRAM
For the modem to calculate buffer size, select Milliseconds.
For a specific buffer depth, select Bits.
This menu indicates whether the Bits or Milliseconds menu is
displayed under Configuration: Interface Buffer Size.

RTS TX-IF CNTRL

TX DATA PHASE
BITS
OFF
NORMAL
4–75
