Comtech EF Data Documentation Update
Subject:
Date:
Document:
Part Number:
Collating Instructions:
Comments:
The following changes provide updated information for page xii and Section 3.2.9. This
information will be incorporated into the next revision.
Change Specifics:
E S
LECTRICAL AFETY
The SNM-1001L Satellite Modem has been shown to comply with the following safety standard:
•
EN 60950: Safety of Information Technology Equipment, including electrical business
machines.
The equipment is rated for operation over the range 85 to 264 volts AC.
power consumption of 55 watts without BUC power supply. Input power increases to 175W
with 100W, 24V BUC power supply at maximum load. Input power increases to 230W with
150W, 48V BUC power supply at maximum load.
F
USES
The SNM-1001L Satellite Modem is fitted with two fuses, one each for line and neutral
connections. These are contained within the body of the IEC power connector, behind a small
plastic flap.
•
Use T3.15A, 20mm
For continued operator safety, always replace the fuses with the
correct type and rating.
IMPORTANT
\\tempefs1\cs_vol\tpubs\manuals\released_word\midas\snm1001l_r1\text\errata a.doc
Errata A
Changes to power consumption and fusing information
May 30, 2003
SNM-1001L Satellite Modem Installation and Operation Manual,
Rev. 1, dated March 17, 2003
MN/SNM1001L.EA1
Attach this page to page xii
fuses.
It has a maximum
