SNM-1001L Satellite Modem
Front Panel Operation
FUNCTION SELECT: REMOTE AUPC: CONFIGURATION:
REMOTE AUPC: MONITOR: 2047 ERRORS (CONDITIONAL)
IMPORTANT
Receive 2047 BER. This is a monitor point that displays the current RX 2047 BER at the far end
of the link. Modems at both ends of the link shall be locked.
If no data is available, "No Data" is displayed.
4.3.6 FUNCTION SELECT: UTILITY
The Function Select: Utility menu is divided into the following categories:
2047 ERRORS
n.n E-e
Conditional: This menu is available when AUPC selection is made from
the Modem Type menu, located under the Utility: Modem Type menu.
Requires the Reed-Solomon Card with AUPC option.
FUNCTION SELECT
UTILITY
4–57
Revision 1
MN/SNM1001L.IOM
