SNM-1001L Satellite Modem
Front Panel Operation
FUNCTION SELECT: UTILITY: DEMODULATOR:
DEMODULATOR TYPE (CONDITIONAL)
IMPORTANT
Receive filter type select. Select Type INTELSAT OPEN, EFD CLOSED, CSC CLOSED, or
FDC CLOSED network receive filtering.
FUNCTION SELECT: UTILITY: DEMODULATOR:
DECODER TYPE (CONTIONAL)
IMPORTANT
Decoder type selection. Select VITERBI, SEQUENTIAL, or TURBO decoder type. The modem
must have the proper hardware enabled.

DEMODULATOR TYPE

INTELSAT OPEN
Conditional: RX FILTER TYPE is selectable only when Custom is
selected for modem type in the Utility: Modem Type menu.
DECODER TYPE
VITERBI
Conditional: Changes only when Modem Type (under Utility: Modem
Type) is in either EFD, Custom, or ASYNC mode.
