SNM-1001L Satellite Modem
Installation
2.2
Installation
The modem arrives fully assembled from the factory. After unpacking the modem, install the
modem as follows:
2.2.1
Modem Installation (Optional)
Refer to Figure 2-1. Use the following mounting kit, KT/6228-1.
Optional: Mounting KIT, KT/6228-1 (Modem to Equipment Rack)
QTY
2
4
2
Tools Required:
Screw Driver
5/32-inch
1. Install the IDU rear support brackets as follows:
Note: It may be necessary to adjust the location of the rear mounting rails of the rack.
Part Number
FP/6138-1
HW/10-32x1/2RK
HW/10-32X1/4 SHC
Phillips
SAE Allen Wrench
a. Install provided rear support bracket onto the mounting rail of the rack. Fasten
with provided bracket bolts.
b. Fasten the provided #10 socket head screws to the rear-side mounting holes on
either side of the chassis modem. Mount the modem into the equipment rack
ensuring that the socket heads engage into the slots of the rear support brackets.
Description
Bracket, Rear Support
Bolt, #10 Rack
Screw, Socket 10-32 x 1/4inch
2–2
Revision 1
MN/SNM1001L.OM
