SNM-1001L Satellite Modem
Remote Control Operation
TX 8PSK Command:
2/3 Response:
IESS-310 Status:
Operation Response:
TX FSK Command:
Output Response:
Status:
Response:
ODU Power Command:
Response:
Status:
Response:
ODU Command:
Reference Response:
Enable Status:
Response:
ODU Power Command:
Monitor Low Response:
Current Status:
Threshold Response:
ODU Power Command:
Monitor Response:
High Status:
Current Response:
Threshold

B.3.2 Demodulator Configuration Commands

Set Command:
Demodulator Response:
Frequency Status:
Response:
Demodulator Command:
Rate Preset Response:
Assignment Status:
Response:
Demodulator Command:
Rate Preset Response:
Selection
Status:
<add/T310_xxx'cr'
>add/T310_xxx'cr''lf']
<add/T310_'cr'
>add/T310_xxx'cr''lf']
<add/FSK_xxx'cr'
>add/FSK_xxx'cr''lf']
<add/FSK_'cr'
>add/FSK_xxx'cr''lf']
<add/ODU_xxx'cr'
>add/ODU_xxx'cr''lf']
<add/ODU_'cr'
>add/ODU_xxx'cr''lf']
<add/ODUR_xxx'cr'
>add/ODUR_xxx'cr''lf']
<add/ODUR_'cr'
>add/ODUR_xxx'cr''lf']
<add/ODUL_xxxx'cr'
>add/ODUL_xxxx'cr''lf']
<add/ODUL_'cr'
>add/ODUL_xxxx'cr''lf']
<add/ODUH_xxxx'cr'
>add/ODUH_xxxx'cr''lf']
<add/ODUH_'cr'
>add/ODUH_xxxx'cr''lf']
<add/DF_nnnnn.nnnn'cr'
>add/DF_nnnnn.nnnn'cr''lf']
<add/DF_'cr'
>add/DF_nnnnn.nnnn'cr''lf']
<add/ADRx_nnnn_mmmm.mmm'cr'
>add/ADRx_nnnn_mmmm.mmm'cr''lf']
<add/ADRx_'cr'
>add/ADRx_nnnn_mmmm.mmm'cr''lf']
<add/SDRx_'cr'
>add/SDRx_'cr''lf']
See DR command.
Where: xxx = ON or OFF.
Where: xxx = ON or OFF.
Where: xxx = ON or OFF.
Where: xxx = ON or OFF.
Where: xxx = 0 to 4000 in 100 mA steps
Where: xxx = 0 to 4000 in 100 mA steps
Where: nnnnn.nnnn = Frequency in MHz, 950.0000 to
1750.0000 in 100 Hz steps steps for non-terminal
frequency display. For terminal frequency mode, the
range will be determined by the LO frequency and
high/low Mix of the ODU.
Where:
x = A, B, C, D, or V [preset designator].
nnnn = 1/2 (QPSK 1/2 Turbo and non-Turbo),
[coder rate], 3/4 (QPSK 3/4Turbo and non-Turbo),
7/8 (QPSK 7/8), BP12 (BPSK 1/2), 8P23 (8PSK
2/3), OQ12 (OQPSK 1/2Turbo and non-Turbo),
OQ34 (OQPSK 3/4 Turbo and non-Turbo), OQ78
(OQPSK 7/8), BPSK (BPSK1/1 Turbo and non-
Turbo), QPSK (QPSK 1/1 Turbo and non-Turbo),
OQSK (OQPSK 1/1 Turbo, and non-Turbo), 2144
(BPSK 21/44 Turbo Only), B516 (BPSK 5/16
Turbo Only), and 8P34 (8PSK 3/4 Turbo Only).
mmmm.mmm = Data rate in kHz.
Burst Mode = nnnn= 1/2
mmmm.nnn = 19.2 or 57.6 kbps
Where: x = A, B, C, D, or V (preset designator).
B–7
Revision 1
MN/SNM1001L.IOM
