SNM-1001L Satellite Modem
Remote Control Operation
Current Command:
Receive Response:
Reed
Solomon N/
K and
Interleaver
value
Descrambler Command:
Type Response:
B.4.3

ODU Configuration Status

Outdoor Unit Command:
Status Response:
Outdoor Unit Command:
Temperature Response:
Outdoor Unit Command:
Phase Lock Response:
Loop
Outdoor Unit Command:
Software Response:
Version
Outdoor Unit Command:
Power Class Response:
Outdoor Unit Command:
Address Response:
Outdoor Unit Command:
TX Output Response:
Outdoor Unit Command:
Power Response:
Leveling
<add/RXRS_'cr'
>add/RXRS_nnn/kkk_ii'cr''lf']
<addDSCR_'cr'
>add/DSCR_xxxxxxxxxxxx'cr''lf']
<add/OUS_'cr'
>add/OUS_'cr'
CURRENT_xxx'cr'
VOLTAGE_xxx'cr'
TEMP_xxx'cr'
PLL_xxx'cr'
CKSUM_xxx'cr'
SFLT_xx'cr''lf']
<add/ODUT_'cr'
>add/ODUT_'cr'
ODU_sxx_yyy'cr''lf']
<add/OPLL_'cr'
>add/OPLL_xxxxxxxx'cr''lf']
<add/OSV_'cr'
>add/OSV_xxcr''lf']
<add/OPC_'cr'
>add/OPC_xxcr''lf']
<add/OADR_'cr'
>add/OADR_xxcr''lf']
<add/ODUO_'cr'
>add/ODUO_xxcr''lf']
<add/ODUP_'cr'
>add/ODUP_xxcr''lf']
The Interface configuration status command causes a block of
data to be returned by the addressed MODEM. The block
reflects the current configuration of the interface. Additional
configuration status of new options and features will always be
appended to the end.
Notes:
1. Data is only returned for TX D&I Overhead.
2. Data is only returned for RX D&I Overhead.
3. Data is only returned for TX IDR Overhead.
4. Data is only returned for RX IDR Overhead.
5. Data is only returned for TX ASYNC Overhead.
6. Data is only returned for RX ASYNC Overhead.
7 Not Used.
thru
14.
Where: nn = N value, kkk = K value and ii = Interleaver value.
Where xxxxxxxxxxxx = EFD MOD V.35, INTELSAT V.35, FDC
MOD V.35, ITU V.35 or OFF.
Current (FLT/OK)
Voltage (FLT/OK)
Temperature (FLT/OK)
Phase Lock Loop (FLT/OK)
Checksum (FLT/OK)
Number of stored faults logged (0 to 10)
Where s = + or – sign, xx = 0 to 99 degree in C and yyy = OK
or OOR (Out of Range).
Where xxxxxxxx = UNLOCKED or OK.
Where xx = 0 to 15.
Where xx = 2 to 60 Watts
Where xx = 1 to 15.
Where xxx = ON or OFF.
Where xxx = ON or OFF.
B–19
Revision 1
MN/SNM1001L.IOM
