SNM-1001L Satellite Modem
Front Panel Operation

FUNCTION SELECT: UTILITY: SYSTEM: REMOTE BAUD RATE

The parity and baud rate settings of the modem are displayed.
To change the modem baud rate and/or parity, press <ENTER>. Press [←] or [→] to position the
cursor over the parameter to be changed. Press [↑] or [↓] to change the parameter. Once the
parameters are displayed as desired, press <ENTER> to set the baud rate and parity. The parity can
be set to EVEN, ODD, or NONE. The baud rate can be set from 150 to 19200 bps.

FUNCTION SELECT: UTILITY: SYSTEM: REMOTE ADDRESS

The current modem address is displayed (1 to 255).
To change the remote address, press <ENTER>. Press [↑] or [↓] to make the selection. Press
[ENTER] to execute the change.
Note: Address 0 is reserved has a Global Address.

FUNCTION SELECT: UTILITY: SYSTEM: REMOTE TYPE

Select EIA-485(2-Wire), EIA-485(4-Wire), or EIA-232.
REMOTE BAUD RATE
9600 bps EVEN
REMOTE ADDRESS
1
REMOTE TYPE
RS485 (2-WIRE)
