FUNCTION SELECT: UTILITY: DEMODULATOR: RX SYMBOL RATE
Status Only. Programmable with 4.800 to 2500 ksps. Provides the symbol rate corresponding to
the data rate, code rate(s), modulation, and overhead (framing) programmed into the demodulator.
4.3.6.4

FUNCTION SELECT: UTILITY: INTERFACE

Select information to view using the [←] [→] arrow keys, then press ENTER.
FUNCTION SELECT: UTILITY: INTERFACE: TX OVERHEAD TYPE
Note: Overhead types are selectable only when Custom is selected for modem type in the Utility:
Modem Type menu.
FUNCTION SELECT: UTILITY: INTERFACE: RX OVERHEAD TYPE
Note: Overhead types are selectable only when Custom is selected for modem type in the Utility:
Modem Type menu.

RX SYMBOL RATE

64.000 Ksps
UTILITY
INTERFACE

TX OVERHEAD TYPE

NONE

RX OVERHEAD TYPE

NONE
