Max Packet Size; Rx-Rs N/K Deep - Comtech EF Data SNM-1001L Installation And Operation Manual

SNM-1001L Satellite Modem
Front Panel Operation
FUNCTION SELECT: UTILITY: DEMODULATOR: MAX PACKET SIZE
Maximum Packet Size: 0 to 1048567 bits.
FUNCTION SELECT: UTILITY: DEMODULATOR: DEMOD SPECTRUM
Programmable vector rotation. Select Normal or Inverted for spectrum reversal of the I and Q
baseband channels.
FUNCTION SELECT: UTILITY: DEMODULATOR:
RX-RS N/K DEEP (CONDITIONAL)
IMPORTANT
N/K is status only.
Deep is interleaver depth and is programmable to a depth of 4, 8, or 16.

MAX PACKET SIZE

2048 BITS
DEMOD SPECTRUM
NORMAL

RX-RS N/K DEEP

225/205
Conditional: This menu is active only when Reed-Solomon (RS) is
installed and RS Option is On (under Configuration: Demodulator).
8
4–72
