Front Panel Operation
FUNCTION SELECT: UTILITY: MODULATOR: TX-RS N/K DEEP
(CONDITIONAL)
IMPORTANT
N/K is status only.
Deep is interleaver depth and is programmable to a depth of 4, 8, or 16.
FUNCTION SELECT: UTILITY:MODULATOR: TX IESS-310 MODE
(CONDITIONAL)
IMPORTANT
An On indication enables 8-PSK 2/3 with Reed-Solomon.

FUNCTION SELECT: UTILITY: MODULATOR: TX MODE

Selection of TX Mode IN Continuous or Burst.

TX-RS N/K DEEP

225/205
Conditional: This menu is active when Reed-Solomon (RS) is installed
and RS is On (under Configuration: Modulator).
TX IESS-310 MODE
Conditional: Only available when 8-PSK option and RS option are
installed and selected.
TX MODE
CONTINUOUS
8
OFF
4–64
