SNM-1001L Satellite Modem
Installation
2.3

Software and Hardware Installation/Upgrades

2.3.1

Reed-Solomon PCB

The TX/RX Reed-Solomon PCBs are installed in the same slots as the Turbo module.
CAUTION
2.3.1.1 Unpacking
CAUTION
1. Remove the Reed-Solomon PCB and mounting hardware from the cardboard
2. Check the packing list to ensure the shipment is complete.
3. Inspect the Reed-Solomon PCB for any shipping damage.
2.3.1.2 Installation
The following tool is required to install the overhead interface PCB:
Phillips  Screwdriver
Use the following information to install the Reed-Solomon Codec PCB as a daughter
card on the main PCB.
Refer Figure 2-3 for installation location of the Reed-Solomon daughter card.
CAUTION
1. Turn off the modem and unplug the power supply.
2. Remove the rear panel retaining screws. Using the finger pulls, slide the main modem
3. Install the Reed-Solomon PCB to the main PCB by mating the male SIMM connectors
Do not mix Reed-Solomon PCBs with Turbo PCB. Damage to the equipment
may be the result.
This equipment contains parts and assemblies sensitive to damage by ESD.
Use ESD precautionary procedures when touching, removing, or inserting
PCBs.
caddypack and anti-static material.
Description
Turn the power off before installation. High current VDC is present. Failure
to do so could result in damage to modem components.
assembly out from the rear of the modem chassis.
with the female SIMM connectors in the position shown in Figure 2-2.
Application
To remove and replace cross-point screws.
2–4
Revision 1
MN/SNM1001L.OM
