5.2.2 PTZ Settings

A PTZ configuration dialog box is provided for you to configure and control the GV-IP Speed
Dome. For details, see Chapter 4 PTZ Control Panel.
5.3 Events & Alerts
For the events of motion detection or I/O trigger, the Administrator can set up two triggered
actions:
1. Send a captured still image by e-mail or FTP.
2. Notify Center Monitoring Stations such as Center V2, VSM or GV-GIS, by video or text
alerts.
To have above triggered actions, you must also set the following features:
Motion Detection (See 5.1.2 Motion Detection)---optional
Input Setting (See 5.2.1 Input/Output Settings)
For e-mail and FTP alerts, it is required to start monitoring (See 5.4 Monitoring).
Note: The Motion Detection function is an optional setting and is activated by default.
Figure 5-6
Configuration Menu
