GV-IPCamera
Vandal Proof IP Dome
Target Vandal Proof IP Dome
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Quick Start Guide
ICH265-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-IPCamera Series and is the answer not in the manual?

Questions and answers

Related Manuals for GeoVision GV-IPCamera Series

Summary of Contents for GeoVision GV-IPCamera Series

  • Page 1 GV-IPCamera Quick Start Guide Vandal Proof IP Dome Target Vandal Proof IP Dome Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. ICH265-A...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

    Contents Caution................iv   Safety Notice ..............iv   Options ................v   Creating GV-IP Camera’s Login Credentials....vi   Note for Adjusting Focus and Zoom......vii   Note for Installing Camera Outdoor......viii   Note for Silica Gel Bags ............x  ...
  • Page 4   1.5 Loading Factory Default............20   1.5.1 Using the Web Interface..........20   1.5.2 Directly on the Camera ..........21 Chapter 2 GV-VD2702 / 2712 / 4702 / 4712....22     2.1 Packing List ................24   2.2 Overview ................26   2.3 Installation ................29  ...
  • Page 5 Chapter 4 Accessing the Camera........59     4.1 System Requirement ..............59   4.2 Accessing the Live View ............59   4.2.1 Checking the Dynamic IP Address ......60   4.2.2 Configuring the IP Address ........61   4.3 Adjusting Image Clarity............63   4.3.1 Using Focus Adjustment Cap........65 Chapter 5 The Web Interface .........66  ...

  • Page 6: Caution

    Caution Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Safety Notice The GV-IPCAM uses a Lithium battery as the power supply for its internal real-time clock (RTC). The battery should not be replaced unless required! If the battery does need replacing, please observe the following: ...

  • Page 7: Options

    Options Optional devices can expand your camera’s capabilities and versatility. Contact your dealer for more information. Device Description The power adapter is available for all Vandal Proof Power Adapter IP Dome. Contact our sales representatives for the countries and areas supported. The GV-PA191 PoE adapter is designed to provide GV-PA191 PoE power and network connection to the cameras over...

  • Page 8: Creating Gv-Ip Camera's Login Credentials

    Creating GV-IP Camera’s Login Credentials The default Administrator and Guest accounts are no longer supported by GV-IPCam H.265 series firmware V1.14 or later. When purchasing a new camera or after resetting it, you need to set up a login username and password for the camera.

  • Page 9: Note For Adjusting Focus And Zoom

    Note for Adjusting Focus and Zoom When adjusting the Focus and Zoom Screws, do not over tighten the Focus and Zoom screws. The screws only need to be as tight as your finger can do it. It is not necessary to use any tools to get them tighter. Doing so can damage the structure of lens.

  • Page 10: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the camera outdoor, be sure that: The camera is set up above the junction box to prevent water from entering the camera along the cables. Any PoE, power, audio and I/O cables are waterproofed using waterproof silicon rubber or the like.
  • Page 11 After opening the camera cover, ensure the screws are tightened and the cover is in place. Make sure the housing cover is properly secured to prevent water from entering and damaging the inner housing.

  • Page 12: Note For Silica Gel Bags

    Note for Silica Gel Bags The silica gel bag loses it effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera, and conceal the gel bag in camera within 2 minutes of exposing to open air.

  • Page 13: Note For Avoiding Ir Reflection

    Note for Avoiding IR Reflection For GV-VD4711 / 5711, to avoid IR reflection and improve camera night view, take precautions for installing the camera on the wall and ceiling. The minimum distances between the camera body and walls, any objects or light sources are: ...

  • Page 14: Chapter 1 Gv-Vd4711 / 5711

    Chapter 1 GV-VD4711 / 5711 These Vandal Proof IP Domes are outdoor cameras designed with IK10+ vandal resistance and IP67 ingress protection. They provide superior night vision with their high power LEDs and allow up to 20 m (65.6 ft), 25 m (82 ft), 30 m (98.4 ft) effective IR distance.

  • Page 15: Packing List

    1.1 Packing List  Vandal Proof IP Dome  Torx Wrench  Power Adapter (excluding  Back Plate GV-VD4711 / 5711)  RJ-45 Connector x 2  Installation sticker Ceiling mount template...
  • Page 16  Long Screw x 4  Screw Anchor x 4  Short Screw x 2  Flat Screw  Conduit Converter  Plastic PG21 conduit connector  Sticker (for Silica Gel Bag)  Ruler  Download Guide  Silica Gel Bag ...
  • Page 17 Note: You can choose to run the wires through a conduit pipe. After you have threaded all the wires, install the supplied conduit converter and plastic PG21 conduit connector with a self-prepared 1/2’’ conduit pipe to the camera. Power will have to be supplied through a PoE adapter, because the power adapter wire does not fit in a 1/2”...

  • Page 18: Overview

    1.2 Overview...
  • Page 19 Name Description The power LED (top) turns on (green) when the power is on and turns off when there is no power supply. The status LED (bottom) LED Indicators turns on (green) when the system operates normally and turns off when system error occurs.

  • Page 20: Installation

    1.3 Installation The Vandal Proof IP Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Note: You can also install the camera:  on a power box (of the 4" square and double gang type) using the standard package ...
  • Page 21 B. Unplug the conduit connector inside the housing and disintegrate the connector. You should have 4 parts: C. Remove the terminal block from the supplied power adapter. (Power adapter is not supplied for GV-VD4711 / 5711) D. Thread the audio wires (optional), TV out wire (optional), adapter wires and I/O wires (optional) through the conduit entry and then through part 1, 2, 3 and 4 of the conduit connector.
  • Page 22 2.6 mm: Audio, BNC 2 mm: DC12V / AC24V 1.8 mm: DIDO IMPORTANT: 1. Use the supplied ruler and leave about 10 cm of power and I/O wires between their connectors on the camera and the cable gland; leave at least 11 cm of audio/TV-out wires between their connectors and the cable gland.
  • Page 23 Install the Ethernet cable. A. Rotate to remove the indicated cap and the plug inside. B. Thread an Ethernet cable (the end with no RJ-45 connector) from the back panel through the cable gland IMPORTANT: Use the supplied ruler and leave about 11 cm of the Ethernet cable between the connector and the cable gland.
  • Page 24 Connect the wires to the camera. Install the terminal blocks to the power adapter and I/O devices. See 1.4.1 Power Connection and 1.4.2 I/O Device Connections. Install the supplied RJ-45 connector to the Ethernet cable. Plug all the connectors to the camera panel. Tip: Unscrew the indicated screws and lift the camera to help you connect the wires.
  • Page 25 Sort out the wires at the back. You can have the wires come out from position A, B or both. The instructions here describe sorting wires for position A. From the back of the camera housing, unscrew and rotate the plate to one side, sort out the wires and secure the plate back.
  • Page 26 Secure the back plate to the ceiling. A. Paste the sticker to the ceiling. The arrow on the sticker indicates the direction that the camera faces. Ceiling mount template B. Drill 3 holes for screws. The recommended ones are indicated as ‘1’.
  • Page 27 Secure the camera to the ceiling. Secure the safety lock to the camera using a short screw. Use flat screw for number 1 and small screw for number 2. Thread all the wires into the ceiling and connect them. Secure the camera using the torx wrench. Access the live view.
  • Page 28 Adjust the camera’s angle, focus and zoom of the camera. Pan Adjustment Tilt Adjustment Rotational Adjustment 10. Replace the silica gel bag and secure the camera cover using the torx wrench.
  • Page 29 IMPORTANT: If the center of the camera view is less than 25° to the ceiling, or lower than the grey line (as illustrated below), disassemble the indicated ring so the view is not obstructed. However, with the ring disassembled, slight reflections may occur.

  • Page 30: Installation Of Weatherproof Shield

    1.3.1 Installation of Weatherproof Shield Optionally purchase a weatherproof shield to protect the camera from rain and snow. Note: A weatherproof shield can be purchased upon request. The pan and tilt angle of the camera is limited by the shield. Remove the housing cover.

  • Page 31: Connecting The Camera

    1.4 Connecting the Camera Connect your Vandal Proof IP Dome to power, network and other wires needed. 1.4.1 Power Connection There are two ways to supply power to the camera:  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.

  • Page 32: Voltage Load Expansion (Optional)

    1.4.3 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC, 10A 125V AC or 5A 100V DC, connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 33: Loading Factory Default

    1.5 Loading Factory Default 1.5.1 Using the Web Interface You can restore factory default settings through the Web interface. On the left menu of Web interface, select Management and select Tools. The Additional Tools dialog box appears. Click the Load Default button in the System Settings section.

  • Page 34: Directly On The Camera

    1.5.2 Directly on the Camera Keep the power and network cables (or PoE) connected to the camera. Use a pin to press and hold the default button on the inner housing. Release the default button when the status LED blinks. This shall take about 8 seconds.

  • Page 35: Chapter 2 Gv-Vd2702 / 2712 / 4702 / 4712

    Chapter 2 GV-VD2702 / 2712 / 4702 / 4712 These Vandal Proof IP Domes are outdoor cameras equipped with a removable IR-cut filter for optimal day and night surveillance. The cameras adhere to IK10 vandal resistance and IP67 ingress protection. They can support H.265 video codec to achieve better compression ratio while maintaining high quality picture.
  • Page 36 Model No. Specifications Description P-Iris, f:2.8 ~ 12 mm, 2 MP H.265, Varifocal GV-VD2702 WDR Pro, Super F/1.7, 1/2.7” lens Low Lux ø 14 mm lens mount P-Iris, 2 MP H.265, f:2.8 ~ 12 mm, Motorized GV-VD2712 F/1.2, 1/2.7” WDR Pro, Super varifocal lens Low Lux ø...

  • Page 37: Packing List

    2.1 Packing List  H.265 Vandal Proof IP Dome  Torx Wrench  Screw x 4  Screw Anchor x 4  TV-Out Wire  Audio Wire x 2  I/O Cable  Installation sticker  Conduit Converter  RJ-45 Connector...
  • Page 38  PG21 Conduit Connector  Waterproof Rubber Sets (for RJ-45 Cat.5 and 12V DC / for RJ-45 Cat.6) Cat.6 Cat.5 (Ø 6 mm) (Ø 5 mm)  Big Concave Hexagon  Small Concave Hexagon Wrench Wrench  Silica Gel Bag ...

  • Page 39: Overview

    2.2 Overview...
  • Page 40 GV-VD2702 / 2712 GV-VD4702 / 4712...
  • Page 41 Name Description The power LED (top) turns on (green) when the power is on and turns off when there is no power supply. The status LED LED Indicators (bottom) turns on (green) when the system operates normally and turns off when system error occurs.

  • Page 42: Installation

    2.3 Installation The Vandal Proof IP Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Note: You can also install the camera to ceilings, wall corners (concave or convex), and poles using optional mounting kits. For details on these installations, see GV-Mount Accessories Installation Guide.
  • Page 43 A. Rotate to remove the cap of the conduit connector. B. Unplug the conduit connector inside the housing and disintegrate the connector. You should have 3 parts: C. Thread the audio wires and I/O wires through the conduit entry and then through part 1, 2, and 3 of the conduit connector. Tip: 1.
  • Page 44 For part 1, there are 5 holes each labeled with its diameter. Remove the plugs and push the wires to the corresponding hole listed below: Plug 3.2 mm: Audio 1.9 mm: DIDO IMPORTANT: Use the supplied ruler and leave at least 14 cm of I/O wires and 10 cm of audio wires between their connectors on the camera and the cable gland.
  • Page 45 If you use cat 6 Ethernet cable, you need to thread the DC 12V wires through the conduit connector. Followings are the corresponding holes. 3.2 mm: Audio 1.9 mm: DIDO 1.9 mm: DC 12V IMPORTANT: Leave more than 10 cm of power wires between their connectors on the camera and the cable gland.
  • Page 46 B. Thread an Ethernet cable (the end with no RJ-45 connector) and the optional power adapter wires from the back panel through the cable gland IMPORTANT: Use the supplied ruler and leave about 14 cm of the Ethernet cable between the connector on the camera and the cable gland.
  • Page 47 Insert the memory card to the memory card slot. For GV-VD2702 / 2712, unscrew the indicated screws and lift the camera to help you insert the memory card. For GV-VD4702 / 4712 : (1) Pull and lift the cover of the memory card slot, and insert the memory card into the slot.
  • Page 48 Sort out the wires at the back. You can have the wires come out from position A and B or from C. Secure the back plate to the ceiling. A. Paste the sticker to the ceiling. The arrow on the sticker indicates the direction that the camera faces.
  • Page 49 F. To optionally install a pipe, use one of the two methods illustrated below depending on the type of the back plate that comes with your camera:  If your plate comes with two knobs, as the figure below, install the supplied conduit converter, with the PG21 conduit connector and a self-prepared 1/2"...
  • Page 50 Secure the camera to the ceiling. Secure the safety lock to the camera with the screw you removed from the back plate in step 2. Safety lock Thread all the wires into the ceiling and connect them. Secure the camera to the back plate with the torx wrench. 10.
  • Page 51 11. Adjust the camera’s angle, focus and zoom of the camera. Pan Adjustment Tilt Adjustment Rotational Adjustment 12. Replace the silica gel bag, press all the wires and cables into the notch and secure the camera cover with the torx wrench.

  • Page 52: Connecting The Camera

    2.4 Connecting the Camera Use a standard network cable to connect the camera to your network. Optionally connect a speaker and an external microphone. Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface.

  • Page 53: I/O Connector

    2.5 I/O Connector The camera supports one digital input and one digital output of dry contact. Supplied I/O Cable Function Digital Output Black White Digital Input For details on how to enable an installed I/O device, see 4.3 I/O Settings, GV-IPCam Firmware Manual.

  • Page 54: Loading Factory Default

    2.6 Loading Factory Default 2.6.1 Using the Web Interface You can restore factory default settings through the Web interface. For details, refer to 1.5.1 Using the Web Interface. 2.6.2 Directly on the Camera Use a pin to press and hold the default button for about 8 seconds. Release the default button when the status LED blinks.

  • Page 55: Chapter 3 Gv-Evd2100 / 3100 / 5100

    Chapter 3 GV-EVD2100 / 3100 / 5100 The Target Vandal Proof IP Dome is an outdoor camera designed with IK10 vandal resistance and IP67 ingress protection. The camera is equipped with an automatic IR-cut filter and IR LEDs for day and night surveillance.

  • Page 56: Packing List

    3.1 Packing List  Target Vandal Proof IP Dome  Torx Wrench  Screw x 4  Screw Anchor x 4  TV-Out Wire  Audio Wires x 2  Installation sticker  RJ-45 Connector  Conduit Converter  Waterproof Rubber Sets (for RJ-45 Cat.5 and 12V DC / for RJ-45 Cat.6) Cat.6...
  • Page 57  Big Concave hexagon Wrench  Small Concave hexagon Wrench  Silica Gel Bag  Sticker (for Silica Gel Bag)  Ruler  Download Guide  Warranty Card...

  • Page 58: Overview

    3.2 Overview 13 12...
  • Page 59 Name Description The power LED (top) turns on (green) when the power is on and turns off when there is no power supply. The status LED (bottom) LED Indicators turns on (green) when the system operates normally and turns off when system error occurs.

  • Page 60: Installation

    3.3 Installation The Target Vandal Proof IP Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Note: You can also install the camera to ceilings, wall corners (concave or convex), and poles using optional mounting kits. For details on these installations, see GV-Mount Accessories Installation Guide.
  • Page 61 Thread an Ethernet cable and/or the adapter wire into the camera. Rotate to remove the indicated cap. Take out and disintegrate the connector. You should have 3 parts: Thread an Ethernet cable (the end without RJ-45 connector) and/or the adapter wire from the back panel.
  • Page 62 Thread an Ethernet cable / adapter wire through part 1 of the connector. According to the below situation, replace the connector if necessary.  For users of PoE with a Cat.5 Ethernet cable, stay with 1a connector on the camera body. ...
  • Page 63 Thread the Ethernet cable and/or the adapter wire through part 2 and 3 of the connector. IMPORTANT: Use the supplied ruler and leave about 14 cm of the Ethernet cable and 10 cm of the adapter wire between their connectors on the camera and the cable gland.
  • Page 64 Thread the audio wires from the back panel, remove the plugs of part 1 and thread through the 3 parts of the connector. Plug Re-install the cap (part 3) with the supplied small concave hexagon wrench. Make sure the cap is installed tightly to waterproof the camera.
  • Page 65 Connect the wires to the camera. Install the terminal block to the power adapter. See 3.4 Connecting the camera. Install the supplied RJ-45 connector to the Ethernet cable. Plug all the connectors to the camera panel. Tip: Unscrew the indicated screws and lift the camera to help you connect the wires.
  • Page 66 Secure the back plate to the ceiling. Paste the sticker to the ceiling. The arrow on the sticker indicates the direction that the camera faces. Drill 4 holes for screws. The recommended ones are indicated as ‘1’. Insert the screw anchors to the 4 holes. Drill A &...
  • Page 67 To optionally install a pipe, use one of the two methods illustrated below depending on the type of the back plate that comes with your camera:  If your plate comes with two knobs, as the figure below, install the supplied conduit converter, with the PG21 conduit connector and a self-prepared 1/2"...
  • Page 68 Secure the camera to the ceiling. Secure the safety lock to the camera with the screw you removed from the back plate in step 2. Safety lock Thread all the wires into the ceiling and connect them. Secure the camera with the torx wrench. Access the live view.
  • Page 69 10. Adjust the camera’s angle, focus and zoom of the camera. Pan Adjustment Tilt Adjustment Rotational Adjustment 11. Replace the silica gel bag, press all the wires and cables into the notch and secure the camera cover with the torx wrench.

  • Page 70: Connecting The Camera

    3.4 Connecting the Camera There are two ways to supply power to the camera:  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.  Plug the power adapter to the terminal block by inserting the striped wire to the right pin (-) and the black wire to the left pin (+).

  • Page 71: Loading Factory Default

    3.5 Loading Factory Default 3.5.1 Using the Web Interface You can restore factory default settings through the Web interface. For details, refer to 1.5.1 Using the Web Interface. 3.5.2 Directly on the Camera Press and hold the default button for about 8 seconds. Release the default button when the status LED blinks.

  • Page 72: Chapter 4 Accessing The Camera

    Chapter 4 Accessing the Camera 4.1 System Requirement To access the GV-IP Camera through the Web browser, ensure your PC connects to the network properly and meets this system requirement:  Microsoft Internet Explorer 8.0 or later Note: For the users of Internet Explorer 8, additional settings are required.

  • Page 73: Checking The Dynamic Ip Address

    4.2.1 Checking the Dynamic IP Address Follow the steps below to look up the IP address and access the Web interface. Note: The computer you use to configure the IP address must be under the same LAN with your camera. The default Administrator and Guest accounts are no longer supported by new firmware versions.

  • Page 74: Configuring The Ip Address

    Click Apply. The camera is now accessible by entering the assigned IP address on the Web browser. To enable the updating of images in Microsoft Internet Explorer, you must set your browser to allow ActiveX Controls and perform a one- time installation of GeoVision’s ActiveX component onto your computer.
  • Page 75 IMPORTANT: If Dynamic IP Address or PPPoE is enabled, you need to know which IP address the camera will get from DHCP server or ISP to log in. If your camera is installed in the LAN, use the GV-IP Device Utility to look up its current dynamic IP address. See 6.2.1 Checking the Dynamic IP Address.

  • Page 76: Adjusting Image Clarity

    4.3 Adjusting Image Clarity You can adjust the image clarity using the GV-IP Device Utility. Make sure that you have connected your GV-IPCAM to the network and install the GV-IP Device Utility program under the same LAN. Note: This feature only applies to the cameras that allow manual focus adjustment.
  • Page 77 For IK10+ models (GV-VD4711 / 5711), hold the supplied Focus Adjustment Cap over the camera view. For details, see 4.3.1 Using Focus Adjustment Cap. Adjust the Zoom Screw and the Focus Screw of the camera slowly until the focus value reaches the maximum. Note: For locations of adjustment screws and rings in each model, see Locations of Adjustment Screws, section, Getting Started...

  • Page 78: Using Focus Adjustment Cap

    4.3.1 Using Focus Adjustment Cap There are two types of Focus Adjustment Caps for GV-VD4711 / 5711. Focus Adjustment Cap Type I: Hold the Focus Adjustment Cap on top of the camera view, keep it close to the lens and slightly tilt to one side to adjust the image.

  • Page 79: Chapter 5 The Web Interface

    Chapter 5 The Web Interface 12 13...
  • Page 80 The Web Interface Name Function Play Plays live video. Stop Stops playing video. Broadcasts to the surveillance site from a remote PC. Note this function is not available for Ultra Bullet Camera and Target Series. For Cube Camera and Advanced Cube Camera, click the Microphone Push to talk button (from the pop-up menu) for the camera to switch between audio transmission and...
  • Page 81 No. Name Function Enables the PTZ Control Panel or the Visual PTZ. PTZ Control Note this function is supported by PTZ Camera Panel and PT Camera, and only partially supported by GV-IP Cameras with motorized varifocal lens. Enables the I/O Control Panel and Visual Automation.

  • Page 82: Chapter 6 Upgrading System Firmware

    Chapter 6 Upgrading System Firmware GeoVision periodically releases updated firmware on the website. The new firmware can be simply loaded into the GV-IPCAM by using the Web interface or IP Device Utility. Before you start  If you use the IP Device Utility for firmware upgrade, the computer used to upgrade firmware must be under the same network of the camera.
  • Page 83 In the Live View window, click the Show System Menu button and select Remote Config. This dialog box appears. Click the Browse button to locate the firmware file (.img) saved at your local computer. Click the Upgrade button to start the upgrade.
