PTZ OSD Control Panel
4

4.10 System Configuration

Figure 4-9
Auto Calibration: There are one horizontal point and one vertical infrared rays check
point in the GV-IP Speed Dome. During installation or maintenance, the Dome's position
may be moved. Therefore, the relative distance between the original set point and the
check point will be changed. If Auto Calibration is enabled, the Dome will automatically
detect the matter and reset the horizontal point back to the original position.
Load Camera Default: Click the button to restore all PTZ settings to the factory default
values. You can also use the Communication Switch on the Dome to restore default PTZ
values (see 1.5 Communication Switch).
67
