GV-IP Speed Dome
User's Manual
Before attempting to connect or operate this product,
ISD2411V101-A-EN
please read these instructions carefully and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-IP and is the answer not in the manual?

Questions and answers

Related Manuals for GeoVision GV-IP

Summary of Contents for GeoVision GV-IP

  • Page 1 GV-IP Speed Dome User's Manual Before attempting to connect or operate this product, ISD2411V101-A-EN please read these instructions carefully and save this manual for future use.
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
  • Page 3 GV-SD220-S (PoE) V1.08 GV-SD2300 (PoE) Outdoor GV-SD2301 (PoE) GV-SD2411 (PoE) V1.01 This Manual provides an overview of the GV-IP Speed Dome and its accessories. The instructions will guide you through the installation and use of the GV-IP Speed Dome as well.

  • Page 4: Table Of Contents

    1.2 System Requirements.....................3 1.3 Packing List ......................4 1.3.1 Indoor GV-IP Speed Dome Camera (GV-SD220) .......... 4 1.3.2 Outdoor GV-IP Speed Dome Camera (GV-SD220-S / GV-SD2300) ....5 1.3.3 Outdoor GV-IP Speed Dome Camera (GV-SD2301 / GV-SD2411) ..... 6 1.4 Functional Panel .....................7 1.4.1 Removing the Camera Cover ..............
  • Page 5 3.11 PTZ Control......................38 3.12 Visual PTZ ......................39 3.13 I/O Control ......................41 3.14 Network Status....................41 Chapter 4 PTZ Control Panel................42 4.1 Preset Settings .....................45 4.2 Cruise Settings .....................46 4.3 Auto Pan Settings ....................47 4.4 PTZ Settings- Sequence Settings .................48 4.5 PTZ Settings- Tour Settings ..................50 4.6 Image Settings- White Balance ................52 4.7 Image Settings- Auto Exposure................53 4.8 Image Settings- Color ...................55...
  • Page 6 5.5.2 I/O Monitoring Settings................96 5.6 Remote ViewLog Player..................97 5.7 Network ........................98 5.7.1 LAN Configuration ..................98 5.7.2 Advanced TCP/IP..................100 5.7.3 IP Filter....................105 5.7.4 SNMP Settings ..................106 5.8 Management.......................107 5.8.1 Date and Time Settings ................107 5.8.2 Storage Settings..................110 5.8.3 User Account...................113 5.8.4 Log Information ..................114 5.8.5 Tools......................115 5.8.6 Language ....................117 Chapter 6 Recording and Playback ..............118...
  • Page 7 8.2 Remote Monitoring with Multi View..............148 8.3 Remote Monitoring with E-Map ..............150 Chapter 9 CMS Configurations ............... 152 9.1 Center V2 ......................152 9.2 Vital Sign Monitor ....................154 9.3 Dispatch Server ....................155 Chapter 10 Smart Device Connection............. 156 Appendix ......................157 A.

  • Page 8: Regulatory Notices

    Regulatory Notices FCC Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 9: Note For Connecting To Gv-System / Gv-Vms

    GeoVision Video Management System for IP cameras. Note for Connecting to GV-System / GV-VMS The GV-IP Speed Dome is designed to work with and record on GV-System / GV-VMS, a video management system. 1. By default, the images are recorded to the memory card inserted in the GV-IP Speed Dome.

  • Page 10: Note For Recording

    Note for Recording 1. By default, the images are recorded to the memory card inserted in the GV-IP Seed Dome. 2. Mind the following when using a memory card for recording: Recorded data on the memory card can be damaged or lost if the data are accessed •...

  • Page 11: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the GV-IP Speed Dome, be sure that any PoE, power, audio and I/O cables are waterproofed using waterproof silicon rubber or the like.

  • Page 12: Note For Water Resistant Coating On Camera Cover

    Note for Water Resistant Coating on Camera Cover The camera cover of GV-SD2301 / GV-SD2411 is treated with a water resistant coating that prevents droplets from forming on the surface. The water resistant coating will slowly wear off after approximately one year depending on the operating environment. Proper care and precautions can prolong the life of the water resistant coating.

  • Page 13: Optional Devices

    GV-Mount Accessories Installation Guide on the Software CD. In-Ceiling Installation The in-ceiling package is used to install the indoor GV-IP Package Speed Dome by embedding the camera to the ceiling. The 24V DC power adapter is designed to convert AC 100V ~ 240V 2.5A to DC 24V 3.75A and supply the power to...

  • Page 15: Chapter 1 Introduction

    Chapter 1 Introduction 1.1 Overview The GV-IP Speed Dome is a network PTZ camera designed for image quality and adaptability in various environments. This camera offers the image of 1080p at 30 fps / 60 fps, 720p at 60 fps and 20x / 30x optical zoom, capable of showing smooth live view with great detail. In...
  • Page 16 Features: • 1/2.8’’ progressive scan CMOS sensor • Full HD 1080p at up to 30 fps and 720p at up to 60 fps for GV-SD220 / GV-SD220-S / GV-SD2300 / GV-SD2301 and 1080p at up to 60 fps for GV-SD2411 •...

  • Page 17: System Requirements

    Introduction 1.2 System Requirements To access GV-IP Speed Dome functions through Web browser, ensure your PC is in good network connection and use one of the following web browsers: • Microsoft Internet Explorer 7.x or later • Google Chrome •...

  • Page 18: Packing List

    Packing List 1.3.1 Indoor GV-IP Speed Dome Camera (GV-SD220) • Indoor GV-IP Speed Dome • Hard-Ceiling Cover • Mounting Plate • GV-IP Speed Dome Software CD • GV-NVR Software DVD • Warranty Card...

  • Page 19: Outdoor Gv-Ip Speed Dome Camera (Gv-Sd220-S / Gv-Sd2300)

    Introduction 1.3.2 Outdoor GV-IP Speed Dome Camera (GV-SD220-S / GV-SD2300) • Outdoor GV-IP Speed Dome • Pendant Tube • Hex Key x 2 • M6 Screw x 4 • Desiccant Pack x 4 • GV-IP Speed Dome Software CD • GV-NVR Software DVD...

  • Page 20: Outdoor Gv-Ip Speed Dome Camera (Gv-Sd2301 / Gv-Sd2411)

    1.3.3 Outdoor GV-IP Speed Dome Camera (GV-SD2301 / GV-SD2411) • Outdoor GV-IP Speed Dome • Pendant Tube • Hex Key x 2 • Rubber ring • RJ-45 Connector • Desiccant Pack x 2 • Data Cable • GV-IP Speed Dome Software CD •...

  • Page 21: Functional Panel

    Introduction 1.4 Functional Panel To access the functional panel of the GV-IP Speed Dome follow the section below to remove its camera cover first. 1.4.1 Removing the Camera Cover • GV-SD220: Rotate to remove the camera cover. camera cover Figure 1-1 •...

  • Page 22: Camera Interior

    1.4.2 Camera Interior 1.4.2.1 GV-SD220/ GV-SD220S / GV-SD2300 Figure 1-4 No. Name Function Restores all the settings to the factory default values. For details Default see 7.3 Restoring to Factory Default Settings. The status LED turns green when the power is on and fades Status when the camera is ready for use.
  • Page 23 Introduction 1.4.2.2 GV-SD2301 / GV-SD2411 Figure 1-5 No. Name Function Restores all the settings to the factory default values. For details Default see 7.3 Restoring to Factory Default Settings. Memory Card Slot Insert a SD / SDHC card to store recording data.

  • Page 24: Installing The Gv-Ip Speed Dome

    1.5 Installing the GV-IP Speed Dome 1.5.1 Indoor GV-IP Speed Dome: Hard-Ceiling Mount Required Items • Indoor packing (supplied) • ceiling screws x 3 (user-prepared) Figure 1-6 1. Secure the mounting plate to the ceiling with self-prepared screws. Figure 1-7...
  • Page 25 1. Cut away a side of the cover if you want to run the cable through. 2. You may also install the indoor GV-IP Speed Dome into the ceiling with optional mounting kits. For detail, see GV-Mount Accessories Installation Guide on the Software...

  • Page 26: Outdoor Gv-Ip Speed Dome: Wall Pendant Mount

    1.5.2 Outdoor GV-IP Speed Dome: Wall Pendant Mount 1.5.2.1 GV-SD220-S / GV-SD2300 Required Items • Outdoor packing (supplied) • Ceiling screws x 4 (user-prepared) Figure 1-10 1. Insert the desiccants to the camera. A. Remove the camera cover using the supplied hex key.
  • Page 27 B. Insert two desiccant packs to the indicated places. Figure 1-12 IMPORTANT: Be sure to conceal the desiccants in the GV-IP Speed Dome within 2 minutes of opening the desiccant pack. C. Insert your micro SD card into the memory card slot. See 1.4.2.1 GV-SD220 / GV-SD220-S / GV-SD2300.
  • Page 28 C. Secure the camera with the supplied M6 screws. Figure 1-14 3. Secure the pendant tube to the wall with self-prepared screws. Note: You may also install the camera to ceilings, wall corners (concave or convex), and poles using optional mounting kits. For details, see GV-Mount Accessories Installation Guide on the Software CD.
  • Page 29 Introduction 1.5.2.2 GV-SD2301 / GV-SD2411 Required Items • Outdoor packing (supplied) • Ceiling screws x 4 (user-prepared) Figure 1-15 1. Insert the desiccants to the camera. A. Remove the camera cover using the supplied hex key. Figure 1-16 B. Insert one desiccant pack to the indicated place. Figure 1-17...
  • Page 30 IMPORTANT: Be sure to conceal the desiccants in the GV-SD2301 / GV-SD2411 within 2 minutes of opening the desiccant pack. C. Insert your SD card into the SD card slot. See 1.4.2.2 GV-SD2301 / GV-SD2411. D. Secure the camera cover with the supplied hex key. Make sure the first two screws to be tightened are diagonal to each other.
  • Page 31 Introduction D. Slide the cap and components through the Ethernet cable as shown below. It is recommended to use the supplied RJ-45 connector. Figure 1-21 E. Move the cap and the components toward the LAN port. Figure 1-22 F. Secure the cap tightly. G.
  • Page 32 Insert the pin connectors of the Data Cable to the indicated area. Figure 1-25 J. Secure the mounting plate with the supplied hex key. 3. Assemble the camera with the pendant tube. A. Secure the safety lock. Figure 1-26 B. Push the rivets into the holes on the pendant tube and rotate clockwise to lock the position.
  • Page 33 Introduction C. Tighten the screws with the supplied hex key. Figure 1-28 D. Secure the pendant tube to the wall with self-prepared screws.

  • Page 34: Connecting The Camera

    2. Connect a standard network cable to the Ethernet cable of the camera. 3. Optionally connect I/O devices, speaker and microphone to the camera. For how to use the PoE function on the Outdoor GV-IP Speed Dome, see 16.1 Connecting the GV-PA901 PoE Adapter.
  • Page 35 Introduction The Data Cable With the Data Cable, you can connect the power, microphone, speaker, and I/O devices to the GV-IP Speed Dome. The Data Cable is illustrated as below. I/O Wires Microphone Speaker Power Adapter Ethernet Figure 1-29 I/O Wire Definition The I/O wires on the Data Cable allow you to connect 4 alarm input and 1 output devices.

  • Page 36: Connecting The Gv-Pa901 Poe Adapter

    1.6.1 Connecting the GV-PA901 PoE Adapter The GV-PA901 PoE Adapter is only for the Outdoor GV-IP Speed Dome. Prepare two Ethernet cables for the connection. Note: PoE function is available for the Outdoor GV-IP Speed Dome only when GV-PA901 PoE Adapter (optional device) is applied for connection.

  • Page 37: Chapter 2 Getting Started

    Chapter 2 Getting Started 2.1 Looking Up the IP Address By default, your GV-IP Speed Dome is assigned with an unused IP address by the DHCP server when the camera is connected to the network. This IP address remains unchanged unless you unplug or disconnect your camera from the network.
  • Page 38 Click the Name or Mac Address column to sort. Figure 2-2 Find the Mac Address of the camera to see its IP address. Changing the IP Address To modify the static IP address or set the camera to a public dynamic IP address, log in the Web interface to access the network setting page.
  • Page 39 Getting Started 4. Select Dynamic IP address, Static IP address or PPPoE and type the required network information. 5. Click Apply. The camera is now accessible by entering the assigned IP address on the web browser. Important: 1. If your camera uses a public dynamic IP address via PPPoE, use the dynamic DNS Service to obtain a domain name linked to the camera’s changing IP address first.

  • Page 40: Accessing Your Surveillance Images

    Follow these steps to access your surveillance images: 1. Open the Internet Explorer browser. 2. Enter the IP address or domain name of the GV-IP Speed Dome in the Location/Address field of your browser. To look up the IP address, see 2.1 Looking Up the IP Address.

  • Page 41: Configuring The Basics

    Getting Started 2.3 Configuring the Basics Once you have installed and logged in the GV-IP Speed Dome, you are ready to configure some of its primary settings through the Web interface: • Date and time adjustment: see 5.8.1 Date & Time Settings.

  • Page 42: Chapter 3 Guest Mode And Live View Panel

    Chapter 3 Guest Mode and Live View Panel This section introduces the features of the guest mode and the live view window. Main Page of Guest Mode Figure 3-1...

  • Page 43: The Live View Window

    Guest Mode & Live View Panel 3.1 The Live View Window In the left menu, click Live View, and then select Camera to see the live video. Figure 3-2 No. Name Function Play Plays live video. Stop Stops playing video. Microphone Talks to the surveillance area from the local computer.
  • Page 44 No. Name Function Clicks to switch to one of the three visual PTZ control modes: Visual PTZ Fixed Direction Move, Random Move or Center Move. For details, see 3.12 Visual PTZ. Click to return the dome view to the home position. To set up a PTZ Home home position, see 4.12 PTZ Settings-Other.

  • Page 45: The Control Panel Of The Live View Window

    Figure 3-3 [Information] Displays the version of the GV-IP Speed Dome, local time of the local computer, host time of the GV-IP Speed Dome, the number of users logging in to the GV-IP Speed Dome and the OCX registration path.

  • Page 46: Snapshot Of A Live Video

    3.3 Snapshot of a Live Video To take a snapshot of live video, follow these steps: 1. Click the Snapshot button (No. 5, Figure 3-2). The Save As dialog box appears. 2. Specify Save in, type the File name, and select JPEG or BMP for Save as Type. You may also choose to display the camera name and/or the date, the text color and image quality for the snapshot.

  • Page 47: Picture-In-Picture And Picture-And-Picture View

    Guest Mode & Live View Panel 3.5 Picture-in-Picture and Picture-and-Picture View The full screen mode provides two types of close-up views: Picture-in-Picture (PIP) and Picture-and Picture (PAP). The two views are useful to provide clear and detailed images of the surveillance area. Picture-in-Picture View With the Picture-in-Picture (PIP) view, you can crop the video to get a close-up view or zoom in on the video.
  • Page 48 Picture-and-Picture View With the Picture-and-Picture (PAP) view, you can create a split video effect with multiple close-up views on the image. A total of 7 close-up views can be defined. Figure 3-5 1. Right-click the live view and select PAP. A row of three inset windows appears at the bottom.

  • Page 49: Alarm Notification

    Guest Mode & Live View Panel 3.6 Alarm Notification After input triggers and motion detection, you can be alerted by a pop-up live video and view up to four captured images. Pop-up live video Captured images Figure 3-6 To configure this function, click the Show System Menu button (No. 12, Figure 3-2), and select Alarm Notify.

  • Page 50: Video And Audio Configuration

    3.7 Video and Audio Configuration You can enable the microphone and speaker for two-way audio communication and adjust the set the number of frames to keep for live view buffer. Click the Show System Menu button (No. 12, Figure 3-2), and select Video and Audio Configuration.

  • Page 51: Remote Configuration

    Guest Mode & Live View Panel 3.8 Remote Configuration You can upgrade the device firmware over the network. Click the Show System Menu button (No. 12, Figure 3-2), and select Remote Config. The Remote Config dialog box will appear. [Firmware Upgrade] In this tab, you can upgrade the firmware over the network. For details, see Chapter 6 Advanced Applications.

  • Page 52: Ptz Control

    3.11 PTZ Control The PTZ control panel is a virtual panel used to control the dome view. With the control panel, the Guest user can carry out Pan, Tilt, Zoom, Focus and Iris functions as well as pre-defined Preset, Sequence, Auto Pan, Cruise and Tour movements. In addition to these functions, the Administrator can also use the control panel to set Presets, Sequence, Auto Pan, Cruise, Tour routes and configure other PTZ settings.

  • Page 53: Visual Ptz

    In addition to the PTZ Control Panel, you may also use a minimized panel, the visual PTZ control panel to operate your GV-IP Speed Dome. This panel can be used to perform all the functions of the guest PTZ control panel except iris control. For functions of guest PTZ control panel, see 3.11 PTZ Control.
  • Page 54 Set Color: Changes the color of the panel. Three kinds of colors are available: Red, Green and Blue. Transparent Degree: Adjusts the transparency level of the panel. Ten levels range from 10% (fully transparent) to 100% (fully opaque).

  • Page 55: I/O Control

    Guest Mode & Live View Panel 3.13 I/O Control The I/O Control window provides real-time graphic displays of camera and I/O status, and alarm events. Additionally, you can force output to be triggered. Figure 3-13 • To display the I/O control window, click the I/O Control button (No. 8, Figure 3-2). •...

  • Page 56: Chapter 4 Ptz Control Panel

    Chapter 4 PTZ Control Panel In this chapter, you will be guided through setup steps for various type of dome view movements (including Preset, Cruise, Auto Pan, Sequence and Tour), image quality settings, (including white balance, exposure and color parameters), schedule settings and PTZ settings.
  • Page 57 PTZ Control Panel Accessing the PTZ Configuration Dialog Box: From the PTZ control panel (Figure 4-1), click Option and select Setup. This dialog box appears. Figure 4-2 PT Speed: determines the speed of panning and tilting of the dome view. The drop-down list contains 5 speed settings: 1 is the slowest speed and 5 the fastest speed.
  • Page 58 Start Menu: Click Open to open PTZ configuration dialog box which contains Image Settings, PTZ settings and general settings related to PTZ function. Figure 4-3 Click OK to save and exit the setup.

  • Page 59: Preset Settings

    PTZ Control Panel 4.1 Preset Settings You can set up a preset position toward which the dome view moves. Up to 255 preset points can be configured and saved. Setting Up a Preset 1. To set up a preset position, use the Pan/Tilt Control keys on the PTZ Control Panel to move the dome to a desired position in Live View.

  • Page 60: Cruise Settings

    4. To set up another Cruise route, repeat Steps 1 to 3, and select a different Cruise number. Starting and Stopping a Cruise To start the GV-IP Speed Dome on a defined Cruise route, click Option (Figure 4-1) on the PTZ Control Panel, click Auto Go and select a Go Cruise number which has been previously set.

  • Page 61: Auto Pan Settings

    Starting and Stopping an Auto Pan To start the GV-IP Speed Dome on an Auto Pan mode, click Option (Figure 4-1) on the PTZ Control Panel, click Auto and select an Auto Pan number which has been previously set. An enabled Auto Pan will repeat until it is stopped by clicking a Pan/Tilt Control key, home key, zoom button or focus button on the PTZ Control Panel.

  • Page 62: Ptz Settings- Sequence Settings

    4.4 PTZ Settings- Sequence Settings You can have the dome view move in a series of predefined movements, called a Sequence. Create a Sequence by linking a number of presets points. Up to 8 Sequences can be created and a minimum of 2 preset points must be selected for a Sequence route to work. Figure 4-4 Setting Up a Sequence 1.
  • Page 63 PTZ Control Panel Starting and Stopping a Sequence To start the dome view on a Sequence route, click Option (Figure 4-1) on the PTZ Control Panel, click Auto Go and select a Go Sequence number which has been previously set. The dome view will continue moving once a Sequence is started.

  • Page 64: Ptz Settings- Tour Settings

    4.5 PTZ Settings- Tour Settings You can set up your GV-IP Speed Dome to move in a combination of preset positions, Sequence, Cruise and Auto Pan. You can configure up to 8 Tour routes. Figure 4-5 Setting Up a Tour 1.
  • Page 65 PTZ Control Panel Starting and Stopping a Tour To start the GV-IP Speed Dome on a Tour route, click Option (Figure 4-1) on the PTZ Control Panel, click Auto Go and select a Go Tour number which has been previously set. An enabled Tour will repeat until it is stopped by clicking a Pan/Tilt Control key, home key, zoom button or focus button on the PTZ Control Panel.

  • Page 66: Image Settings- White Balance

    4.6 Image Settings- White Balance The White Balance setting is used to adjust the colors of camera image so that it reflects normal coloring under different environment lighting. Figure 4-6 Auto: The camera automatically performs color adjustments. This option is suitable for environments with unchanging lightings.

  • Page 67: Image Settings- Auto Exposure

    PTZ Control Panel 4.7 Image Settings- Auto Exposure Figure 4-7 Auto Exposure: provides controls on camera exposure. Select Full Auto, Shutter Priority, Iris Priority or Bright Priority. The default is Full Auto. Full Auto: The camera adjusts its exposure automatically. By enabling this option, you can also adjust the Slow Shutter below.
  • Page 68 Max Gain Limit: analyzes the brightness of the scene and enhances the image when it is pixilated and noisy due to insufficient light. Use the drop-down list to select a value. The higher the value, the stronger the gain effect. Slow Shutter: This option is only available under the Full Auto mode.

  • Page 69: Image Settings- Color

    PTZ Control Panel 4.8 Image Settings- Color The Color settings are used to adjust color contrast, sensitivity and gain. Figure 4-8 Luminance (low lux): Enable this function to make low-light views clearer. Color Gain: Adjusts the contrasts of the dome view. ICR: Defines how the camera’s IR-cut filter works.

  • Page 70: Image Settings- Mask

    4.9 Image Settings- Mask The Mask is used to block out sensitive areas from view. You can create and save up to 8 Masks. The Mask size will stay proportional to the zoom, which increases when zoomed in and decreases when zoomed out. The Mask will be fixed to the position where it is first created.
  • Page 71 PTZ Control Panel D. To modify the Mask size, repeat Steps 2B and 2C. 2. To disable a Mask, select the Mask number from Mask, select Off and click the Save button. 3. To create a new Mask, select a different Mask number and follow steps 1B to 1D. 4.

  • Page 72: Image Settings- Other

    4.10 Image Settings- Other Figure 4-10 Digital Zoom: With this option, users can enable or disable the 12x Digital Zoom. The Digital Zoom will be activated after the Optical Zoom level is fully reached. The default setting is Off. Focus: Sets the focus mode of the dome. Select Auto for the dome to automatically focus after scene change and PTZ movement (such as preset or any function executed from the PTZ control panel);...
  • Page 73 PTZ Control Panel Backlight: Backlight Compensation (BLC) is used to compensate AGC in adjusting color intensity. For scenes with strong light in the background and dim light in the foreground, AGC is not effective because AGC averages the light intensity of a whole frame. BLC compensates for this characteristic by restricting AGC to adjust color intensity of a specific area.

  • Page 74: Ptz Settings- Schedule

    4.11 PTZ Settings- Schedule You can set up a schedule for the dome to perform Preset, Sequence, Auto Pan, Cruise or Tour during a specified time. Up to 8 sets of schedule can be configured and saved. Figure 4-11 1. Select a schedule number from the Index drop-down list. 2.

  • Page 75: Ptz Settings- Other

    PTZ Control Panel 4.12 PTZ Settings– Other This page contains speed and duration settings of Auto Pan and PT. Figure 4-12 Auto Pan: An Auto Pan is a pan movement of the dome view between two user-defined positions. For setup steps, see 4.3 Auto Pan Mode Settings. Speed: Select the panning speed.
  • Page 76 Set Home Position: First adjust the dome view to a desired position and click this button to set it as your Home Position.

  • Page 77: System Configuration

    PTZ Control Panel 4.13 System Configuration Figure 4-13 Freeze: Skip showing camera images while traveling from one preset to another. This function is disabled by default. Mechanic Flip: The dome view rotates 180° when it is tilted to the maximum angle (vertically 0°...
  • Page 78 Load Camera Default (Exclude PTZ): Click the button to restore default settings to Image Settings and System Configuration in PTZ Configuration dialog box (Figure 4-13). Self test: Click this button to re-calibrate the GV-IP Speed Dome to maintain its accuracy.

  • Page 79: Chapter 5 Administrator Mode

    Administrator Mode Chapter 5 Administrator Mode The Administrator can access and configure the GV-IP Speed Dome over the network. The configuration categories include: Video and Motion, I/O Control, Events and Alerts, Monitoring, Recording Schedule, Remote ViewLog, Network, and Management. Figure 5-1...
  • Page 80 Corresponding Section for Configuration Menu Find the topic of interest by referring to the indicated section. 5.1.1 Video Settings 5.1 Video and Motion 5.1.2 Motion Detection 5.1.3 Text Overlay 5.2.1 Input Settings 5.2 I/O Control 5.2.2 Output Settings 5.3.1 Email 5.3.2 FTP 5.3.3 Center V2 5.3.4 VSM...

  • Page 81: Video & Motion

    Administrator Mode 5.1 Video & Motion The GV-IP Speed Dome supports dual streams, Streaming 1 and Streaming 2, which allow separate codec and resolutions settings for a single video transmission. In a bandwidth-limited network, such as mobile phone surveillance, this dual-stream feature allows you to view live video in lower resolution and codec (Streaming 2), and record in highest resolution 1920 x 1080 and codec H.264 (Streaming 1) at the same time.

  • Page 82: Video Settings

    5.1.1 Video Settings Figure 5-2 a...
  • Page 83 Administrator Mode Figure 5-2 b [Name] Rename the camera. The camera name will appear on the Live View. To display the camera name, see 3.9 Camera Name Display. [Connection Template] Select the type of your network connection. Unless you select Customized, this option will automatically bring up the recommended video resolution, frame rate, bandwidth and GOP size.
  • Page 84 Configure the codec type, signal format, resolution and frame rate. Select the codec type H.264 or MJPEG for the main stream/sub stream. Choose the Flicker Hz value between 60 Hz or 50 Hz. The default is 60 Hz. The supported resolutions are listed blow: Streams Ratio Supported Resolution...
  • Page 85 This function is enabled by default. [Text Overlay Settings] Enable this option to play videos over HTTP protocol or GeoVision software integration. Overlaid with camera name: Includes camera names on live and recorded videos. Overlaid with date stamps: Includes date stamps on live and recorded videos.

  • Page 86: Motion Detection

    5.1.2 Motion Detection Motion detection is used to generate an alarm whenever movement occurs in the dome view. You can configure up to 8 detection zones with different sensitivity values. Create at least one detection zone to enable this function. Figure 5-3 1.
  • Page 87 Administrator Mode 6. For the camera to ignore environmental changes such as rain or snow, select the Ignore environmental changes. 7. To reduce video noise when the lighting condition changes, select Noise Tolerance. 8. To trigger the alarm output when motion is detected, select the Output 1 and click the Apply button.

  • Page 88: Text Overlay

    5.1.3 Text Overlay The Text Overlay allows you to overlay any text in any place on the camera view. Up to 16 text messages can be created on one camera view. The overlaid text will be saved in the recordings. Figure 5-4 1.

  • Page 89: I/O Control

    Administrator Mode 5.2 I/O Control This section introduces how to configure the I/O devices connected to the GV-IP Speed Dome. 5.2.1 Input Settings The GV-IP Speed Dome can connect up to 4 input devices. Figure 5-6a...
  • Page 90 Figure 5-6b Name: Edit the input name. Normal State: Set up the input state to trigger actions by selecting Open Circuit (N/O) or Grounded Circuit (N/C). Latch Mode: Enable the mode to have a momentary output alarm. Trigger Digital Output Relay: Select the output to be triggered once the input is activated.
  • Page 91 Administrator Mode Set PTZ camera to Auto Function: Enable this option for your GV-IP Speed Dome to perform one of the Auto Functions, including Preset, Sequence, Auto Pan, Cruise or Tour upon input trigger. Input on: Direct the GV-IP Speed Dome to the specified preset point when the input is triggered.

  • Page 92: Output Setting

    5.2.2 Output Setting The GV-IP Speed Dome can connect 1 output device. Figure 5-7 Select Enable to start the output device. Choose the output signal that mostly suits the device you are using: N/O (Open Circuit), N/C (Grounded Circuit), N/O Toggle, N/C Toggle, N/O Pulse and N/C Pulse.

  • Page 93: Events & Alerts

    Administrator Mode 5.3 Events & Alerts For the events of motion detection or I/O trigger, the Administrator can set up two triggered actions: 1. Send a captured still image by e-mail or FTP. 2. Notify Center Monitoring Stations such as Center V2, VSM or GV-GIS, by video or text alerts.

  • Page 94: E-Mail

    5.3.1 E-mail After a trigger event, the GV-IP Speed Dome can send an e-mail to a remote user containing a captured image. Important: To send e-mail alert upon motion, be sure to set up the detection area on the Motion Detection page. For details, see 5.1.2 Motion Detection.
  • Page 95 Administrator Mode 7. If the SMTP Server needs authentication, select Need authentication to login and type a valid Username and Password to log in the SMTP server. If the SMTP Server needs a secure connection (SSL), select This server requires a secure connection. 8.

  • Page 96: Ftp

    5.3.2 FTP You can also send the captured image to a remote FTP server for alerts. Important: To send FTP alert upon motions, be sure to set up the detection area on the Moti Detection page. For details, see 5.1.2 Motion Detection. Figure 5-9 [Upload to an FTP Server] 1.
  • Page 97 Select Continuously send images upon trigger events (Input). [Act as FTP Server] 1. Enable FTP access to the GV-IP Cam: The GV-IP Speed Dome acts as an FTP server, enabling users to download AVI files. 2. Use alternative port: Modify the FTP port if needed or use the default port 21 3.

  • Page 98: Center V2

    5.3.3 Center V2 After a motion or an I/O triggered event, the central monitoring station Center V2 can be notified by live videos and text alerts. Up to two Center V2 servers can be connected. For live monitoring through Center V2, you must already have a subscriber account on each of the Center V2 server.
  • Page 99 Administrator Mode 3. Port Number: Match the port to Port 2 on Center V2. Or keep the default value 5551. For details, see 8.1 Center V2. 4. User Name: Type a valid user name to log in to Center V2. 5.

  • Page 100: Vsm

    5.3.4 VSM After a motion or an I/O triggered event, the central monitoring station VSM can be notified by text alerts. Up to two VSM servers can be connected. For live monitoring through VSM, you must already have a subscriber account on each of the VSM server. Important: To notify the VSM upon motions, be sure to set up the detection area on the Moti Detection page.
  • Page 101 Administrator Mode 3. Port Number: Match the port to Port 2 on VSM. Or keep the default value 5609. For details, see 8.2 VSM. 4. User Name: Type a valid user name to log into VSM. 5. Password: Type a valid password to log into VSM. 6.

  • Page 102: Backup Center

    5.3.5 Backup Center The connection to the GV-Backup Center allows you to back up another copy of recordings and system log to the GV-Backup Center on an offsite location while the camera is saving these data to the memory card. The GV-Backup Center provides a PC-based storage and backup solution.
  • Page 103 Administrator Mode 3. Port Number: Match the communication port on the GV-Backup Center. Or keep the default value 30000. 4. User Name: Type a valid user name to log into the GV-Backup Center. 5. Password: Type a valid password to log into the GV-Backup Center. 6.

  • Page 104: Gv-Video Gateway / Gv-Recording Server

    5.3.6 GV-Video Gateway / GV-Recording Server The GV-IP Speed Dome can be connected with up to two GV-Video Gateway / GV-Recording Server. To send the video images to the GV-Video Gateway or GV-Recording Server, you must already have an account on each of the GV-Video Gateway / GV-Recording Server with the user name and password specified below.
  • Page 105 Administrator Mode 3. Port Number: Match the communication port specified on GV-Video Gateway / GV-Recording Server. Or keep the default value 50000. 4. User Name: Type a valid user name to log into GV-Video Gateway / GV-Recording Server. 5. Password: Type a valid password to log into GV-Video Gateway / GV-Recording Server. 6.

  • Page 106: Viewlog Server

    5.3.7 ViewLog Server The ViewLog Server is designed for remote playback. This server allows you to remotely access the recorded files saved at the GV-IP Speed Dome and play back video with the ViewLog player. The ViewLog Server is enabled by default. To disenable the function, select Enable to uncheck.

  • Page 107: Rtsp / 3Gpp

    RTSP. Disable Authentication: Authentication is enabled by default with which the ID and password of the GV-IP Speed Dome are required when accessing live view through the RTSP command. For details on remote monitoring with mobile phones, see 9.4 3G Mobile Phone.

  • Page 108: Monitoring

    Input: Manually starts I/O monitoring. When the sensor input is triggered, its associated output will be activated for alerting, the GV-IP Speed Dome will be activated to send video to Center V2, and/or direct the GV-IP Speed Dome to a preset point. To configure the input and output settings, see 5.2.1 Input / Output Settings.

  • Page 109: Recording Schedule

    Administrator Mode 5.5 Recording Schedule The schedule settings activate recording and I/O monitoring during specific time periods each day. 5.5.1 Recording Schedule Settings You can set up the schedule for recording. Figure 5-17 Span 1- Span 3: Set a different recording mode for each time span during the day. Each day can be divided into 3 time spans, shown as Span 1, Span2, and Span 3.

  • Page 110: I/O Monitoring Settings

    5.5.2 I/O Monitoring Settings You can set the I/O Monitoring Schedule Settings to enable I/O monitoring. Figure 5-18 Span 1-3: Set different time frames during the day to start I/O monitoring. Each day can be divided into 3 time frames, represented by Span 1 to Span 3. The time frame you specify is effective from Monday through Sunday.

  • Page 111: Remote Viewlog Player

    Administrator Mode 5.6 Remote ViewLog Player You can play back the files recorded at the GV-IP Speed Dome over TCP/IP network using Remote ViewLog player. For first-time users, install the Remote ViewLog player from the Software CD to your computer and make sure the ViewLog Server function is enabled on your camera.

  • Page 112: Network

    5.7 Network The Network section includes some basic but important network configurations that enable the GV-IP Speed Dome to be connected to a TCP/IP network. 5.7.1 LAN Configuration According to your network environment, select among Static IP, DHCP and PPPoE.
  • Page 113 DDNS function to obtain a domain name linking to the camera’s changing IP address. For details on Dynamic DNS Server Settings, see 5.7.2 Advanced TCP/IP. Note: To establish connection through a broadband modem, you may refer to this article: ftp://geo-demo-japan.dipmap.com/Technotice/GV_IP_Devices/How to access GV-IP Camera through broadband modem.pdf...

  • Page 114: Advanced Tcp/Ip

    5.7.2 Advanced TCP/IP This section introduces the advanced TCP/IP settings, including DDNS Server, HTTP port, streaming port and UPnP.
  • Page 115 DDNS (Dynamic Domain Name System) provides a convenient way of accessing the GV-IP Speed Dome when using a dynamic IP. DDNS assigns a domain name to the GV-IP Speed Dome, so that the Administrator does not need to go through the trouble of checking if the IP address assigned by DHCP Server or ISP (in xDSL connection) has changed.
  • Page 116 DDNS V2 and obtain a host name. Figure 5-21 3. Host Name: Type the host name used to link to the GV-IP Speed Dome. For the users of GeoVision GVDIP Server and GeoVision DDNS Server, it is unnecessary to fill the field because the system will detect the host name automatically.
  • Page 117 To apply QoS to GV-IP Speed Dome, all network routers must support QoS and QoS must be enabled on these devices. To enable the QoS on GV-IP Speed Dome, enter a Differentiated Services Code Point (DSCP) value.
  • Page 118 0 which means QoS is disabled. Click Apply to finish. [Network Connection Check Settings] When the network connection check is enabled, the GV-IP Speed Dome will check for Internet connection and reboots automatically when it is disconnected from the Internet. This...

  • Page 119: Ip Filter

    Administrator Mode 5.7.3 IP Filter The Administrator can set IP filtering to restrict access to the GV-IP Speed Dome. Figure 5-22 To enable the IP Filter function: 1. Enable IP Filtering: Enable the IP Filtering function. 2. Filtered IP: Type the IP address you want to restrict the access.

  • Page 120: Snmp Settings

    1. Select Enable SNMPv1 SNMPv2c to enable the function. 2. To enable access to Read/Write Name, type a community string. This will serve as a password to allow read and write access to the GV-IP Speed Dome from the SNMP software.

  • Page 121: Management

    Administrator Mode 5.8 Management The Management section includes the settings of date, time and user account. Also you can view the firmware version and execute certain system operations. 5.8.1 Date and Time Settings The date and time settings are used for date and time stamps on the image. Figure 5-24...
  • Page 122 [Date & Time on GV-IP Speed Dome] Displays the current date and time on the GV-IP Speed Dome. [Time Zone] Sets the time zone for local settings. Select Enable Daylight Saving Time to automatically adjust the GV-IP Speed Dome for daylight saving time. Type the Start Time and End Time to enable the daylight saving function.
  • Page 123 Administrator Mode Figure 5-25 GV-System Figure 5-26 GV-VMS...

  • Page 124: Storage Settings

    5.8.2 Storage Settings Based on Linux ext3 file system, the GV-IP Speed Dome supports memory cards for video and audio recordings. You need to format the memory card by using the following Storage Settings. After being formatted, the memory card will be ready to use by Linux OS of the camera.
  • Page 125 Administrator Mode Keep days (1-255): Specify the number of days to keep the files from 1 day to 255 days. When both Keep days and Enable recycling are selected, the system recycles (deletes) stored files when any of the limitations is met. For example, if the keep day is specified as 60 (days), the files will be recycled at the 61 day even when the storage is not full.
  • Page 126 The storage device status is shown in the status column: Status Description Formatting The storage device is being formatted. The format of the storage device is not recognizable or the device can Unknown not be found. Storage formatting is successful. Try Mount The camera is attempting to connect to the storage device.

  • Page 127: User Account

    Administrator Mode 5.8.3 User Account You can change the login name and password of Administrator, Guest and FTP Server User. • The default Administrator login name and password are admin. • The default Guest login name and password are guest. To allow a Guest user log in without entering the username and password, select Disable authentication for guest account.

  • Page 128: Log Information

    5.8.4 Log Information The log contains dump data that is used by service personnel for analyzing problems. Figure 5-30...

  • Page 129: Tools

    Administrator Mode 5.8.5 Tools This section allows you to execute certain system operations and view the firmware version. Figure 5-31...
  • Page 130 [Database Status] Displays the repairing status of database. [Firmware Update] This field displays the firmware version of the GV-IP Speed Dome. [IP Speed Dome Model Information] This field displays the model name of the GV-IP Speed Dome. [System Settings] Click the Load Default button to restore all the settings of GV-IP Speed Dome (except settings in the PTZ Configuration dialog box) to factory default settings.

  • Page 131: Language

    Administrator Mode 5.8.6 Language You can change the language for the Web interface. Figure 5-32 Use the Language drop-down list to select a language for the Web interface. By default, the language on the Web interface will be the same with the one used for the operating system.

  • Page 132: Chapter 6 Recording And Playback

    Chapter 6 Recording and Playback The GV-IP Speed Dome can record video and audio directly to the memory card. You can play back the recorded files on the GV-System / GV-VMS or over the TCP/IP network. Note: See Note for Connecting to GV-System / GV-VMS at the beginning of the manual.

  • Page 133: Playback

    Recording and Playback 6.2 Playback You can use the following methods to play back video files recorded at the GV-IP Speed Dome: • Playback by using the memory card by connecting it directly to the GV-System / GV-VMS through a memory card reader •...
  • Page 134 1. Install the Ext2Fsd from the Software CD. Note: If you are using Windows 8 or Windows Server 2012, change its compatibility before installing the Ext2Fsd program: A. Right-click the Ext2Fsd program and select Properties. This dialog box appears. Figure 6-1 B.
  • Page 135 Recording and Playback 2. On your desktop, click Start, select Programs, locate the Ext2Fsd folder and select Ext2 Volume Manager. All the connected drives are shown. Figure 6-2 3. For the first-installation, execute the Ext2Fsd Service. From the Ext2 Volume Manager window, select Tools and select Service Management.
  • Page 136 4. Mount the storage drive to your computer. From the Ext2Fsd Volume Manager window, right-click the storage drive and select Ext2 Management. This dialog box appears. Figure 6-4 Under the Mount point & driver letter section, select Automatically mount via Ext2Mgr, specify a disk drive using the drop-down list and click Apply On the Ext2 Volume Manager window, the storage drive is successfully mounted to your computer when it is indicated with the disk drive you specified.

  • Page 137: Playback Over Network

    Recording and Playback 6.2.2 Playback over Network You can also play back the files recorded at the GV-IP Speed Dome over TCP/IP network using the Remote ViewLog function. 1. The camera needs to allow the remote access with ViewLog Server activated. See 5.3.7 ViewLog Server.

  • Page 138: Playback Of Daylight Saving Time Events

    6.2.4 Playback of Daylight Saving Time Events On GV-System, you can retrieve and play back the events recorded during the Daylight Saving Time (DST) period from the GV-IP Speed Dome. You can also connect the memory card to GV-System for playback.

  • Page 139: Chapter 7 Advanced Applications

    7.1 Upgrading System Firmware GeoVision periodically updates the latest firmware to the company website. You can update your GV-IP Speed Dome firmware through the Web interface or GV IP Device Utility included in the Software CD. Important Notes before You Start Before you start updating the firmware, please read these important notes: While the firmware is being updated, the power supply must not be interrupted.

  • Page 140: Using The Web Interface

    7.1.1 Using the Web Interface 1. In the Live View window, click the Show System Menu button (No. 12, Figure 3-2) and select Remote Config. This dialog box appears. Figure 7-2 2. Click the Browser button to locate the firmware file (.img) saved at your local computer. 3.

  • Page 141: Using The Gv Ip Device Utility

    2. Double-click the IP Device Utility icon created on your desktop. This dialog box appears. Figure 7-3 3. Click the Search button to locate the available GV-IP Speed Domes on the same LAN. Or click the New button and assign the IP address to locate a GV-IP Speed Dome on the Internet.
  • Page 142 5. Click the Browse button to locate the firmware file (.img) saved at your local computer. 6. If you like to upgrade all the GV-IP Speed Domes in the list, check Upgrade all devices. 7. Type Password, and click Upgrade to start the upgrade.

  • Page 143: Backing Up And Restoring Settings

    7.2 Backing Up and Restoring Settings With the IP Device Utility included on the Software CD, you can back up the configurations in the GV-IP Speed Dome, and restore the backup data to the current unit or import it to another unit.
  • Page 144 To restore the settings: 1. In Figure 7-4, click the Import Settings tab. This dialog box appears. Figure 7-7 2. Click the Browse button to locate the backup file (.dat). 3. Select Upgrade all devices to import the settings into the same type of device in the same LAN.

  • Page 145: Restoring To Factory Default Settings

    Advanced Applications 7.3 Restoring to Factory Default Settings You can restore the system settings of GV-IP Speed Dome to factory default by pressing the Default button on the camera or through the Web interface. System settings include all settings on the Web interface, excluding the settings in the PTZ Configuration dialog box. To restore PTZ configuration settings (Figure 4-3) to default, you will have to go to the PTZ configuration setting page in the Web interface.
  • Page 146 To Restore Settings in PTZ Configuration: 1. Access the PTZ Configuration dialog box. For details, see Calling Up the PTZ Control Panel and Accessing the PTZ settings, Chapter 4. 2. On the PTZ Configuration dialog box (Figure 4-3), select System Configuration. This dialog box appears.

  • Page 147: Verifying Watermark

    Advanced Applications 7.4 Verifying Watermark The watermark is an encrypted and digital signature embedded in the video stream during the compression stage, protecting the video from the moment of creation. Watermarking ensures that an image is not edited or damaged after it is recorded. To enable the watermark function, see [Watermark Setting], 5.1.1 Video Settings.

  • Page 148: The Watermark Proof Window

    7.4.3 The Watermark Proof Window Figure 7-9 The controls in the window: No. Name Description Open File Opens the recording. First Frame Goes to the first frame of the file. Play Plays the file. Previous Frame Goes to the previous frame of the file. Next Frame Goes to the next frame of the file.

  • Page 149: Downloading Videos From The Memory Card

    Advanced Applications 7.5 Downloading Videos from the Memory Card When connections of GV-IP Speed Dome to the GV-System / GV-VMS are lost, recordings are automatically saved to the memory card inserted in the GV-IP Speed Dome. To automatically synchronize and download recordings from the memory card to a local folder, install and execute the GV-SDCardSync Utility program.
  • Page 150 3. To configure synchronization, network and startup settings, see the steps below. Figure 7-11 [Synchronization] Synchronize automatically at an interval: Automatically synchronize videos from micro SD card to a local folder at the specified interval. Synchronize automatically at: Automatically synchronize videos from micro SD card to a local folder at the specified time.
  • Page 151 Advanced Applications 4. By default, downloads are saved to :\GvSDCardSync and are not recycled automatically. To configure the storage and recycling settings, select the Storage tab on the Setting window. This page appears. Figure 7-12 [Recycle] Recycle when the storage space is less than (GB): Specify a minimum free space of your local storage for file recycling.

  • Page 152: The Gv-Sdcardsync Utility Window

    Storage Space Shows the storage space of the designated hard drive. Note: 1. The synchronization time is recorded according to the system time of the GV-IP Speed Dome. 2. The logs are deleted once the GV-SDCardSync Utility is re-activated.

  • Page 153: Chapter 8 Dvr Configurations

    1. The above maximum number of streams is based on the camera’s maximum resolution 1920 x 1080 and the codec H.264. 2. By default, GV-IP Speed Dome is in dual streams and will take up 2 streams when connected to GV-System / GV-VMS.

  • Page 154: Setting Up Ip Cameras On Gv-System

    8.1 Setting Up IP Cameras on GV-System Follow the steps below to manually connect your GV-IP Speed Dome to GV-System. Note: The following instructions are based on V8.5.5 software and user interfaces. 1. On the GV-System’s main screen, click the Configure button, select System Configure, select Camera Install and click IP Camera Install.
  • Page 155 2. Click Add Camera. This dialog box appears. Figure 8-3 3. Type the IP address, username and password of the GV-IP Speed Dome. Modify the default HTTP port if necessary. 4. Select GeoVision from the Brand drop-down list and select GV-SD220 from the Device drop-down list.
  • Page 156 Codec type: The live view codec and resolution settings are displayed here. Resolution: Select resolutions for preview and recording. 5. Click Apply. The GV-IP Speed Dome is added to the list. 6. Click the listed camera, select Display position and select a channel number to map the camera to a channel on the GV-System.

  • Page 157: Customizing Camera Settings On Gv-System

    DVR Configurations 8.1.1 Customizing Camera Settings on GV-System After the GV-IP Speed Dome is connected and assigned with a display channel, you can configure the camera’s settings such as frame rate, codec type and resolution. Right-click the camera to see the following list of options:...
  • Page 158 GIS function of the GV-System (Configure button < Accessories < Enable Local GIS). Automatically Adjust DST: If enabled, the time on the GV-IP Speed Dome’s Web interface will be synchronized with the time of the GV-System when DST period starts or...
  • Page 159 , select Toolbar , click Configure and select Camera Install. Figure 8-7 . This dialog box appears. Click Add Camera Figure 8-8 Type the IP address, username and password of the GV-IP Speed Dome. Modify the default HTTP port 80 if necessary.
  • Page 160 Select GeoVision and model name from the Brand drop-down list and select the GV-IP Speed Dome from the Device drop-down lists. This dialog box appears. Figure 8-9 In the dialog box, configure the options which may vary depending on camera brands.
  • Page 161 DVR Configurations Click Apply to add the GV-IP Speed Dome to the list. To connect the added camera, click the box besides the ID column. Upon successful connection, the Status icon shows green, with the video resolution and bit rate being displayed in the correspondent columns.

  • Page 162: Remote Monitoring With Multi View

    8.2 Remote Monitoring with Multi View You can use the Multi View to monitor the video and I/O devices connected to the GV-IP Speed Dome. Note: Multi View is not supported by GV-VMS. Connecting to GV-IP Speed Dome The Multi View program is available in the GV-System applications, and is also included in the Software CD as an independent program.
  • Page 163 DVR Configurations 6. Select GV-IP Camera, GV-IP Speed Dome from the Device drop-down list. Type the host name, IP address, user name and password of the GV-IP Speed Dome. Modify the default VSS port 10000 if necessary. Figure 8-11 7. Click Save to establish connection.

  • Page 164: Remote Monitoring With E-Map

    8.3 Remote Monitoring with E-Map You can use the Remote E-Map to monitor the video and I/O devices connected to the GV-IP Speed Dome. Creating an E-Map for the GV-IP Speed Dome With the E-Map Editor, you can create an E-Map for the GV-IP Speed Dome and I/O devices connected to the dome.
  • Page 165 Download page. Install the E-Map program before you can run it. 4. On the Remote E-Map window, click the Login button and select the GV-IP Speed Dome host to access its videos and I/O devices. The valid user name and password are required to log in the GV-IP Speed Dome.

  • Page 166: Chapter 9 Cms Configurations

    Settings button, select System Configure, click the Network tab, and check Accept connections from GV-Compact DVR, Video Server & IP Cam. Keep the default port 5551 for the Port 2 option, or modify it to match the Center V2 port on the GV-IP Speed Dome.
  • Page 167 5 minutes and you set 10 minutes, which means the total display time will be 15 minutes. For further information on how to mange the received video from the GV-IP Speed Dome, see GV-CMS Series User’s manual.

  • Page 168: Vital Sign Monitor

    Connective Port field, keep the default value 5609 for the Port 2 option, or modify it to match the VSM port on the GV-IP Speed Dome. Figure 9-5 For further information on how to mange the received video from the GV-IP Speed Dome, see GV-CMS Series User’s manual.

  • Page 169: Dispatch Server

    To enable connecting to the GV-IP Speed Dome, click the Server Setting button on the toolbar, and enable Allow Video Server Login as Subscriber from Port. Keep the default port 5551, or modify it to match the Center V2 port on the GV-IP Speed Dome.

  • Page 170: Chapter 10 Smart Device Connection

    You can access the live view and play back recordings on your mobile devices using the mobile application GV-Eye. Android Smartphone, tablet, iPad, iPhone and iPod Touch are supported. For details on system requirements, installation and setup, visit our website: http://www.geovision.com.tw/english/5_8_App.asp...

  • Page 171: Appendix

    Appendix Appendix A. The CGI Command With GV-IP Speed Dome, you can obtain a snapshot of the live view or access the User Account Web interface simply by executing CGI commands. For a GV-IP Speed Dome with e following details: IP address: 192.168.2.11...

  • Page 172: Rtsp Protocol Support

    B. RTSP Protocol Support The GV-IP Speed Dome supports R TSP protocol for both video and audio streaming. For RTSP command, enter: rtsp://<IP of the GV-IP Speed Dome:8554/<CH No.>.sdp For e xample, rtsp://192.168.3.1 11:8554/CH001.sdp Note: The RTSP server must be enabled on the Web interface. See Figure 5-14.

  • Page 173: Settings For Internet Explorer 8

    Appendix C. Settings for Internet Exp lorer 8 If you use Internet Explorer 8, it is required to complete the following setting. . Set the Security to Medium-high (default). 2. Enable Allow previously unused ActiveX controls to run without prompt. 3.

This manual is also suitable for:

Gv-sd220Gv-sd220-sGv-sd2300Gv-sd2301

Table of Contents
