7. Run the Data and Ethernet cables down through the center hole of the T-Bar and connect
cables to the GV-IP Speed Dome.
Figure 2-14
8. Mount the Dome body to the bracket and rotate it clockwise.
Figure 2-15
9. Tighten the screw to fix the GV-IP Speed Dome.
Figure 2-16
10. Fix the Decoration Ring to the bracket and then put the optical cover back.
Note: Make sure the optical cover is removed before fixing the Decoration Ring to the
bracket.
