4.7 Image Setting- Auto Exposure

Auto Exposure: Defines how Auto Exposure works.
On the models GV-SD010-18X, GV-SD010-36X, GV-SD010-S18X and GV-SD010-S36X,
you have options of Full Auto, Manual, Shutter Priority, Iris Priority and Bright Priority.
On the models GV-SD010-23X and GV-SD010-S23X, you have options of Full Auto, AGC
Priority, Shutter Priority and Iris Priority.
The options included in Auto Exposure:
Full Auto: All exposure controls work together automatically. You can also freely
adjust Slow Shutter, Auto ICR, Backlight and Wide Dynamic Range settings.
Manual: Users can adjust Slow Shutter, Shutter, G Gain and Iris values.
•
This option is only available on the models GV-SD010-18X, GV-SD010-36X,
GV-SD010-S18X and GV-SD010-S36X.
AGC Priority: The AGC takes main control of exposure, and both Shutter and Iris
function automatically with AGC. You can freely adjust G Gain and Backlight settings.
•
This option is only available on the models GV-SD010-23X and GV-SD101-S23X.
Shutter Priority: The shutter speed takes main control of exposure, and both
IRIS and AGC function automatically with shutter speed.
• On the models GV-SD010-18X, GV-SD010-36X, GV-SD010-S18X and
GV-SD010-S36X, you can freely adjust Slow Shutter and Shutter settings.
•
On the models GV-SD010-23X and GV-SD010-S23X, you can freely adjust
Shutter and Backlight settings.
62
Figure 4-6
