4.9 Image Setting- Other

Exposure Compensation: Adjust the brightness for auto exposure. The selectable
values are from 0 to 7.
ICR: Turn IR Cut Filter Removal on or off. To automatically adjust ICR, see 4.7 Image
Setting-Auto Exposure.
Aperture: Adjust the enhancement of object edges.
• On the models GV-SD010-18X, GV-SD010-36X, GV-SD010-S18X and
GV-SD010-S36X, you can manually adjust the level from 0 to 15.
• On the models GV-SD010-23X and GV-SD010-S23X, you can select either Auto
mode or Manual mode. Under the Manual mode, the adjustable levels range from 0 to
15.
Freeze: Skip showing camera images while traveling from one preset to another.
Picture Flip: Rotate the image 180 degrees. The function is automatically disabled when
the Mask is enabled (see 4.8 Image Setting-Mask).
66
Figure 4-8
