Page 1: Quick Start Guide
Quick Start Guide GV-IP Speed Dome Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. ISD220200-QG-D... - Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
-
Page 3: Table Of Contents
........ 2 2.1.2 Outdoor GV-IP Speed Dome ........3 2.2 Overview................2.3 Installation................5 2.3.1 Indoor GV-IP Speed Dome: Hard-Ceiling M ount... 5 2.3.2 Outdoor GV-IP Speed Dome: Wall Mount..... 7 2.4 Connecting the Cables............10 2.5 Accessing the Camera ............ - Page 4 3. G V-SD200 / SD200-S..........3.1 Packing List ................. 32 3.1.1 Indoor GV-IP Speed Dome......... 32 3.1.2 Outdoor GV-IP Speed Dome ........33 3.2 Overview................34 3.3 Installation................35 3.3.1 Indoor Speed Dome Mount: Surfac e Mount ....35 3.3.2 Outdoor Speed Dome Mount: Mini...
- Page 5 3.13 Upgrading System Firmware ..........3.14 Restoring to Default Settings..........62...
-
Page 6: Introduction
1. Intr oduction Welcome to the GV-IP Speed Dome Quick Start Gui de. In the following sections, you will be guided through the basic installations and configurat ns of the G -SD220/GV-SD220-S/ GV-SD200/GV-SD200-S. For detai informa tion, see GV-IP Speed Dome U ser’s Manual on the... -
Page 7: Gv-Sd220 / Sd220-S
2. GV-SD220 / SD220-S 2.1 Packing List 2.1.1 Indoor GV-IP Speed Dome • • Indoor GV-IP Speed Dome Hard-Ceiling Cover • GV-IP Speed Dome • Mounting Pla Software CD • GV-NVR Software DVD... -
Page 8: Outdoor Gv-Ip Speed Dome
GV-SD220 / SD220-S 2.1.2 Outdoor GV-IP Speed Dome • • Outdoor GV-IP Speed Dome Pendant Tube • • Hex Keys x 2 M6 Screws x 3 • • Desiccant pack x 4 GV-IP Speed Dome Software CD • GV-NVR Software DVD... -
Page 9: Overview
2.2 Overview Name Description Restores all the settings to th e factory default values. ault For details, see 2.13 Restoring to Default Settings. The status LED turns green when the power is on and Status fades when the camera is ready for use. Power The power LED turns green when the power is on. -
Page 10: Installation
GV-SD220 / SD220-S 2.3 Installation There are multiple ways to install the GV-IP Speed Dome. Only the standard installation methods are introduced in the Quick Start Guide. For details on optional installations, see Installing the GV-SD220/220-S IP Speed Dome, Chapter 5, GV-Mount Installation Guide on the Software CD. - Page 11 Secure the indoor GV-IP Speed Dome to the mounting plate. Loosen the screw on the mounting plate Align the camera to the mounting plate and rotate the camera body to the right. Tighten the screw. Put on the hard-ceiling cover.
-
Page 12: Mount
GV-SD220 / SD220-S 2.3.2 Outdoor GV-IP Speed Dome : Wall Pendant Mount Requir Items • • eili... - Page 13 Insert the desiccants to the camer IMPORT ANT: Be sure to conceal t he desiccants in the GV-IP Speed Dome wit hin 2 minutes f opening t he desiccant pack. Remove the camera cover using the supplied hex key.
- Page 14 GV-SD220 / SD220-S Insert two desiccant packs to the indicated places. Follow ste p 1A to s ecure the camera cover with the supplied hex key. As mble the camera wi the pendant tube. Thread the c amera c able through the pendant tube. Rotate the camera and lock it to the pendant tube.
-
Page 15: Connecting The Cables
2.4 Connecting the Cables With the Data Cable, you can connect the pow er, microphone, speaker, and I/O devices to the GV-IP Spee d Dome. The Data Cable is illustrated as below. I/O Wires Microphone Speaker Power Adapter Ethernet Wire Definition Orange rm In 1... -
Page 16: Accessing The Camera
Note: For users of Internet Explorer 8, additional settings are required. For details, see Appendix C. For more details, see 1.2 System Requirements, GV-IP Speed Dome GV-SD220 User’s Manual on the Software CD. With non-IE browsers, Motion Detection, Text Overlay, two-way audio and GPS map settings are not supported. -
Page 17: Looking Up The Ip Address And Logging In
2.5.2 Looking Up the IP Address and Logging In By def ault, the IP address of your GV-IP Speed Dome is ass igned by the DHCP server unless your router does not support DHCP. In this case, the default IP address will be 192.168.0.10. Follow the steps bel... - Page 18 IP a ddress conflict with other GeoVision IP device on e same N. For details, see Changing the IP Address in 2.1 Looking Up the IP Address, GV-IP Speed Dome GV-SD220 User’s Manual on the Software CD.
-
Page 19: The Web Interface
2.6 The Web Interface Name Description Play Plays live video. Stop Stops playing video. Talks to the surveillance area from the local Microphone computer. Speaker Listens to the audio around the camera. - Page 20 Visual PTZ. Show Brings up these functions: Alarm Notify, Video System and Audio Configuration, Remote Config, Show Menu Camera Name and Image Enhance. For detail, see 3.1 The Live View Window, GV-IP Speed Dome GV-SD220 User’s Manual on the Software CD.
-
Page 21: The Ptz Control Panel
2.7 The PTZ Control Panel k the PT ontrol button on the Live View windo w and select PTZ ntrol P anel . The PTZ Control Panel appears... - Page 22 Sequence, Auto Pan, Cruise and Tour) • Image settings • Option PTZ settings • System settings For detail, see PTZ Control Panel, Chapter 4, GV-IP Speed Dome GV-SD220 User’s Manual on the Software CD. Show Preset Opens and closes the number pad.
-
Page 23: Configuring A Preset Position
2.8 Configuring a Preset Position You can set oves. Up to up a preset position toward which the dome view m 255 preset points can be configured and saved. Setting Up a Preset Use th e direction keys on the PTZ Control Panel to move t he dome to a desir ed position in Live View. - Page 24 GV-SD220 / SD220-S ng a Preset To m ove the dome view to a previously defi ned preset position, click Option on the PTZ Control Panel, click Preset Go, and select a Preset number which has been set up.
-
Page 25: Configuring A Sequence Route
2.9 Configuring a Sequence Route can have the dome view move in a series of predefined movem ents. Creat e a Sequence by linking a number of presets points. Up to 8 equences can be created and a minimum of 2 preset points must b sele cted for a Sequence route to work. - Page 26 GV-SD220 / SD220-S Click Open and click Sequence located under PT Z Setting on the left menu. Use the Index drop-down list to select the Sequence group number to be configured. Up to 8 Indexes (Sequence groups) can be created. One Sequence group can include up to 16 Preset Points.
- Page 27 Starting and Stopping a Sequence To start the dome view on a Sequence route, click Option on the PTZ Control Panel , click Auto Go and select a Go Sequence number which has been previously set. The dome view will continue mo ving once a Sequence is started.
-
Page 28: Configuring A Cruise
3, and select a different Cruise number. Starting and Stopping a Cruise To start the GV-IP Speed Dome on a defined Cruis e route, click Option on the PTZ Control Panel, click Auto Go and select a Go Cruise number which has been previously set. -
Page 29: Configuring An Auto Pan
2.11 Configuring an Auto Pan The GV-IP Speed Dome can pan up to 360° endlessly to survey the horizontal view between 2 pre-defined positions. You can configure up to 8 sets of Auto Pan routes. Setting Up an Auto Pan Set up the vertical position of your GV-IP Speed Dome first. - Page 30 GV-SD220 / SD220-S Starting and Stopping an Auto Pan To start the GV-IP Speed Dome on an Auto Pan mode, click Option on the PTZ Control Panel, click Auto and select an Auto Pan number which has been previously set. To stop an Auto Pan, click any button on the PTZ...
-
Page 31: Configuring A Tour
2.12 Configuring a Tour You can set up your GV-IP Speed Dome to move in a combination of preset positions, Sequence , Cruise and Auto Pan. You can configure up to 8 Tour routes. Setting Up a Tour Follow the steps in Accessing the PTZ Configuration Dialog Box above and click Open to display the PTZ Configuration dialog box, click Tour located under PTZ Setting on the left menu. - Page 32 Index number. Click Save to complete the settings. Starting and Stopping a Tou To start the GV-IP Speed Dome on a Tour route, clic k Option on the PTZ Control Panel, clic k Auto Go and select a Go Tour number which has been previously set.
-
Page 33: Upgrading System Firmware
2.13 Upgrading System Firmware GeoV ision periodically updates the latest f irmware to the company website. can update your GV-IP Speed Dome firmware through the Web interf ace or GV IP Device Utility included i n the Software CD. For details on... - Page 34 GV-SD220 / SD220-S In the Live View window, click the Show System Menu button and select Remote Config. This dialog box appears Click the Browser button to locate the firmware file (.img) saved at your local computer. Click the Upgrade button to start upgrading.
-
Page 35: Restoring To Default Settings
2.14 Restoring to Default Settin There are two parts to the GV-IP Speed Dome setti ngs: • System settings: this refers to all the settings except the PTZ settings • PTZ configuration settings: this refers to settings in the PTZ configuration dialog box 2.14. -
Page 36: Restoring Ptz Configuration Settings Only
Access the PTZ Configuration dialog box. For details, see Calling Up the PTZ Con trol Panel and Accessing the PTZ settings, Chapter 4, GV-IP Speed Dome GV -SD220 User’s Manual on the Software CD. On the PTZ Conf iguration dialog bo x, select System Configuration. - Page 37 3. GV-SD200 / S D200-S 3.1 P acking List 3.1.1 Indoor GV -IP Speed Dome • Indoor GV • Hard -IP Speed Ceiling Mount Dome (G M ountD603) • Term • M3 Standard S inal Block crew (x • GV •...
-
Page 38: Gv-Sd200 / Sd200-S
GV-SD200 / SD200-S 3.1.2 Outdoor GV-IP Speed Dome • Outdoor GV-IP Speed Dome • M3 Standard Screw (x1) • M3 Security Screw (x1) • M5 Standard Screw (x1) • M5 Security Screw (x1) • Outdoor M • Waterproof Rubber nting Kit (GV-Mount 902) •... -
Page 39: Overview
3.2 Overview Name Description LAN / High Power Connects to a 10/100 Ethernet or High Power PoE (for GV-SD200 only). I/O Terminal Block Connects to I/O devices. For details, see 3.4 Connecting the Cables in the Quick Start Guide. Power Port Connects to power of AC 24V. -
Page 40: Installation
Dome. In this Quick art Guide, we only show you the standard mountin g methods with the standard packing. For other mounting methods, refer to GV-IP Speed Dome GV-SD200 User’s Manual. 3.3.1 Indoor Speed Dome Mount: Surface Mount GV-M... - Page 41 Fasten the Hard Ceiling Mount with the three supplied M4 Self-tapping Screws. Thread the connected cables and wires through the center hole of the Mount and connect the cabl e to the camera body. Users can choose o hide the c ables and wires inside the ceiling, and put the rubber from the accessory package to fill the gap at the side...
- Page 42 GV-SD200 / SD200-S Fasten the screw at the side of the Fixing P late. After installing the Camera on the Hard Ceiling Mount, put the Dome Cover back, and use a flat screw drive to fas ten two supplied Flat Screws on the Dome Cover.
-
Page 43: Outdoor Speed Dome Mount: Mini Pendent Mount
3.3.2 Outdoor Speed Dome Mount: Mini Pendent Mount Required items: • Outdoor packing (supplied) • Wall screws x 4 (user-prepared) Make a cable entry hole on the wall to recess the cables. You can also push up the Cable Entry Board on the Mini Pendent Mount’s Mounting Plate to place the cables, as shown in the photo below. - Page 44 GV-SD200 / SD200-S Attach the Waterproof Rubber to the Mi ni Pendent Mount. Run the cable(s) through the Mini Pendent Mount. Note: Bloc the cable entr y hole with the supplied sponge to avoid insects ente ring the Pendent Mount. The sponge can be placed in two w s a wn in the illu rations below.
- Page 45 Co necting Powe fin tion AC 24_1 AC 24_2 Note: If you are using GeoVision’s optional power adaptors, connect the green or green/yellow wire to GND. The two remaining wires are interchangeable, and both wires can be connected to AC_2 or AC_1.
- Page 46 GV-SD200 / SD200-S Connecting Alarm I/O Definition Definition Alarm_Out_NC_1 Alarm_Out_COM_2 Alarm_Out_NO_1 Alarm_Out_COM_1 Alarm_In_4 Alarm_In_3 Alarm_Out_NC_2 Alarm_In_2 Alarm_Out_NO_2 Alarm_In_1 Connecting Audio Definition Line_Out Line_In...
-
Page 47: Accessing The Camera
3.5 Accessing the Camera 3.5.1 System Requirements o perform the GV-IP Speed Dome via web brow ser, ensure your PC is in good network connection, and use one of the following web browsers. • Internet Explorer 7.0 or later •... -
Page 48: Looking Up The Ip Address And Logging In
On the GV-IP Utility window, click the button to search for the GV-IP Speed Dome. Click the Name or Mac Address column to sort. Find the camera with its Mac Address to see the IP address. - Page 49 Type the default username and password admin. Click OK to access the Web interface. When accessing the GV-IP Speed Dome for the first time, you must set your browser to allow a one-time installation of DC Viewer onto your computer.
-
Page 50: The Web Interface
GV-SD200 / SD200-S 3.6 The Web Interface After logging on to the GV-IP Speed Dome, users will see the Home page as shown below: Main Tabs Language Selection Time Display Focus Mode Select Video Format Display Mode PTZ Control Panel... -
Page 51: The Ptz Control Panel
3.7 The PTZ Control Panel Click the button on the home page. The PTZ Control Panel appears. Button Description Moves the camera to 8 directions. Zooms in. Shortens the apparent distance between the camera and the view. Zooms out. Lengthens the apparent distance between the camera and the view. - Page 52 GV-SD200 / SD200-S Button Description Focuses in. Changes the sharpness of the view. Focuses out. Changes the sharpness of the view. Automatically adjusts the focus. Enlarges the aperture opening. Automatically adjusts the aperture opening. Reduces the aperture opening. Moves to a defined Preset point. Preset Starts a defined Cruise path.
-
Page 53: Configuring A Preset Position
3.8 Configuring a Preset Position You can set up a preset position toward whic h the do me view moves. Up to 256 preset points can be configured and saved. Setting up a Preset Click the PTZ tab and select Preset from the left menu of the Web interface. - Page 54 GV-SD200 / SD200-S Using a Preset To move the dome view to a previously defined P reset point, click the Home tab and click on the PTZ Control Panel button . Select the defined number from the Preset drop-down list and click the button.
-
Page 55: Configuring A Sequence Route
3.9 Configuring a Sequence Route can have the dome view move in a series of predefined movement Creat e a Sequence by linking a number of presets points. Up to 8 equences can be created and a minimum of 2 Preset Points must be sele cted for a Sequence line to work. - Page 56 GV-SD200 / SD200-S Click the Edit button under Sequence Setting. Use the Sequence Line drop-down list to select a Sequence route number to be configured. Use the Name drop-down list to select the desired Preset points for the Sequence route. One Sequence line include up to 64 Preset points.
- Page 57 10. Return to the Sequence page. Use the Sequen ce Line drop-down list to select a Sequence route number and clic k Go to test your settings. Starting and Stopping a Sequence To start t he dome view on a Sequence route, click the Home tab, click the PTZ Control Panel button and select a Sequence number which has been previously set.
-
Page 58: Configuring A Cruise
You can set u path consisting of different directions, angles, and zooms for the GV-IP Speed Dome to follow. Up to 8 Cruises can be created. Setting up a Cruise Click the PTZ tab and select Cruise from the left menu of the Web interface. - Page 59 Use the Cruise Path drop-down list to sel ect a Cruise path number and click the Run button to test your settings. Starting and St opping a Cruise To start the dome view on a Cruise path, click the H ome tab, click the PTZ Control Panel button and select a Cruise number which has been...
-
Page 60: Configuring An Auto Pan
GV-SD200 / SD200-S 3.11 Configuring an Auto Pan The GV-IP Speed Dome can pan up to 360° endlessly to survey the horizontal view between 2 pre-defined positions. Y ou can configure up to 4 sets of Auto Pan paths. Setting up a Auto Pan Click the PTZ tab and select Auto Pan from the left menu of the Web interface. - Page 61 Note: The zoom ratio of an A t u o Pan’s Start Point will persist throughout the whole path. Starting and Stopping a Auto Pan To start the dome view on an Auto Pan path, click the Run button on the Auto Pan page.
-
Page 62: Configuring A Tour
GV-SD200 / SD200-S 3.12 Configuring a Tour You c an set up your GV-IP Speed Dome to move in a combination of Preset Sequenc e, Cruise and Auto Pan. You can configure up to 16 Tour routes. Setti ng up a Tour ick the PTZ tab and select Tour Function from the left menu of th Web interface. - Page 63 Click the Edit button under Tour Function Setting. Use the Tour Function drop-down list to select a number to be configured. Use the Function drop-down list to select a Preset, Sequence, Cruise or Auto Pan. Type a number in the No. field to specify the Preset, Sequence, Cruise, and Auto Pan.
- Page 64 GV-SD200 / SD200-S Starting and Stopping a Tour To start the dome view on a Tour path, click the Run button on the Tour Function page. The dome view will continue moving once a Tour is started. To stop the movements, move the cursor on the dome view and drag it to any directions.
- Page 65 The interruption of power supply during updating causes not only update failures but also damages to your camera. In this case, please contact your sales representative and send your device back to GeoVision for repair. Do not turn the power off for 10 minutes after the firmware is updated.
- Page 66 GV-SD200 / SD200-S Click the System tab and select Software Upgrade from the left menu. Click the Browse button and select one firmware file to be uploaded. Note: Do not change the upgrade file name, or the system will fail to find the file.
- Page 67 3.14 Restoring to Default Settin You can restore the camera to factory default settings using the Web interface or directly on the camera. On the Web interface, you can choose to do a full restoration or partial restoration of default settings. Using the Web Interface Click the System t ab and selec Factory Default f...
- Page 68 GV-SD200 / SD200-S Directly on the Camera To restore to default settings directly on the camera, use a pointy object, such as the tip of a pen to hold down the Load default button (Button E below) for about 30 seconds while the power is on. The lens will rotate briefly when load default is completed.
