GeoVision GV-IP Speed User Manual page 156

1 & 2: Commutation Signal Terminal Block
1 (J1)
Pin Definition
RX+ Audio GND
RX- Audio Out
TX+ Audio In
TX- Audio GND
ISOG Not Functional
VGND Video GND
VIDEO Video
3 & 4: Power Signal Terminal Block
3 (J5)
Pin Definition Pin
1 AC 24V
2 FG
3 AC 24V
5: Power Plug AC Plug In.
6: Power Adaptor
7: Power Supply Voltage Switch
or 220V and 230V to meet your environment requirement.
Note: One Power Box can only work with one GV-IP Speed Dome of either indoor or outdoor
type. It is not allowed to connect multiple GV-IP Speed Domes to one Power Box.
146
2 (J6)
Pin Definition
RX+ Audio GND
RX- Audio Out
TX+ Audio In
TX- Audio GND
ISOG Not Functional
VGND Video GND
VIDEO Video
4 (J2)
Definition
1 AC 24V
2 FG
3 AC 24V
Select the correct power input between 100V and 115V
