GeoVision GV-IP Speed User Manual page 160

Type
Model GV-SD010-18X
Operation
Pan Travel 360° endless
Tilt Travel -10° ~ 190°
Manual Speed 0.5° ~ 90°/s
Preset 256
Preset Accuracy 0.225°
Preset Speed 5° ~ 400°/s
Sequence 8
Auto Pan 4
Cruise 4
Proportional Pan & Tilt On / Off (Pan and tilt speed proportional to zoom ratio)
Resume after
Yes
Power Loss
Home Function Preset, Sequence, Auto pan, Cruise
Auto Flip Digital / Mechanical / Off
Digital Slow Shutter On / Off
Motion Detection On / Off
Wide Dynamic Range On / Off
Day/Night:
On / Off
Mechanical IR Cut Filter
Image Inverse On / Off
Image Freeze On / Off
Alarm Input 4
Alarm Output 1
Alarm Reaction Preset, Sequence, Auto pan, Cruise
General
Operating Temperature 0°C ~ 40°C; 32°F ~ 104°F
Waterproof Standard N/A
Dimensions Ø 131 x 226 mm; 5.2 x 8.9 in
Weight 1.6 kg; 3.5 lbs
Input
NTSC
Output 24V AC ± 10%, 1.5A
Power Source
Input
PAL
Output 24V AC ± 10%, 1.5A
Power Consumption 20 W
Heater N/A
Fan-On Threshold 35°C / 95°F
Humidity 20% ~ 90% (non-condensing)
Regulatory CE, FCC, RoHS
Applications
Network Storage GV-NVR, GV-System, GV-Recording Server
3G Mobile Phone Built-in player for 3GPP / ISMA
Live Viewing IE , GV-MultiView
CMS Server support GV-Control Center, GV-Center V2, GV-VSM, GV-GIS
150
Indoor
GV-SD010-23X
100 / 115V AC, 0.63A, 50-60HZ
220 / 230V AC, 50 / 60HZ, 0.2A
GV-SD010-36X GV-SD010-S18X
-45°C ~ 50°C; -49°F ~ 122°F
IP66 standard (Outdoor series)
Ø 172 x 302.5 mm; 6.7 x 11.9 in /
Ø 190 x 302.5 mm; 7.5x 11.9 in (with sunshield)
2.6 kg; 5.7 lbs
Input 100 / 115V AC, 1.6A, 50-60HZ
Output 24V AC ± 10%, 3A
Input 220 / 230V AC, 50 / 60HZ, 0.4A
Output 24V AC ± 10%, 3A
65 W (with Heater)
On: -7°C / 19.4°F ; Off: 3°C / 37.4°F
Outdoor
GV-SD010-S23X GV-SD010-S36X
