7.1 Setting Up IP Cameras

To set up IP cameras on the GV-System, follow these steps:
Note: The following instructions are based on V8.4 software and user interfaces.
1. On the main screen, click the Configure button, select General Setting, select Camera /
Audio Install and click IP Camera Install. This dialog box appears.
•
To automatically set up an IP camera, click Scan Camera to detect any IP cameras
on the same LAN.
•
To manually set up an IP camera, click Add Camera.
•
To import IP cameras from the IP Device Utility, click Import Camera.
•
To map IP devices through the GV IP Device Utility program, click IP Device Utility.
The following steps are the example of manual setup.
2. Click Add Camera. This dialog box appears.
Figure 7-3
Figure 7-2
DVR Configurations
7
115
