2.1.2 Flush Mount (Indoor Use Only)

With the optional T-Bar Ceiling Mount, the GV-IP Speed Dome of Indoor Type can be
mounted into the ceiling, revealing a small part of the Dome body.
Necessary items include:
•
GV-IP Speed Dome (Indoor Type)
•
Data Cable (supplied)
•
Ethernet Cable
•
T-Bar Ceiling Mount (optional)
•
Red Sticker (supplied with T-Bar Ceiling Mount)
•
Decoration Ring (supplied)
Follow the steps:
1. Disassemble the wing (as shown in the picture below) from the T-Bar Ceiling Mount, and
take out the supplied screw in the small bag.
Figure 2-9
20
Figure 2-8
