GeoVision GV-IP Speed User Manual page 134

To define how to display the received video on motion detection and input trigger from the
GV-IP Speed Dome, click the Preference Setting button and select System Configure. This
dialog box appears.
Figure 8-3
Manual close channel: Closes the triggered camera view manually.
Close the camera view when motion stopped: Closes the triggered camera
view automatically when motion stops.
Post Motion: Specify the duration of the camera view remaining on the
monitoring window after motion stops.
Camera send by I/O trigger will monitor: Specify the duration of the camera
view remaining on the monitoring window when an I/O device is triggered.
To keep the camera view remaining on the monitoring window even after the
alarm is finished, click the right-arrow button, and uncheck Latch Trigger. Then
the camera view will keep remaining on the monitoring window for the specified
time. For example, the alarm is triggered for 5 minutes and you set 10 minutes,
which means the total display time will be 15 minutes.
For further information on how to mange the received video from the GV-IP Speed Dome, see
GV-CMS Series User's manual.
124
